Daedong NS4710 - Page 49

3
SPECIFICATIONS
3
-
5
※
The specications are subject to change without notice.
ITEM
MODEL
NS4710 NS6010 NS4710H NS5310H NS6010H
Hydraulic
Lift Capacity
@
24 in. behind lift point
kgf (lbs)
1,131 (2,493)
@lift point kgf (lbs) 1,334 (2,940)
No.of standard remote valves (Rear) 1
PTO
Rear
Type Independent
PTO shaft specica-
tions
SAE 1-3/8, 6 spline
1 / 2 / 3 stages rpm 540
Min. turning radius
(With one rear wheel braked) m (ft)
3.37 (11.04)
Weight with ROPS and AG tires kgf (lbs) 1,827 (4,028)
Max. Draw-bar vertical load kgf (lbs) -
Max. Trailer loading weight kgf (lbs) -
