NS4710 / NS6010 / NS4710H / NS5310H / NS6010H
4
-
28
SHUTTLE SHIFT LEVER
(1) Shuttle Shift Lever
(F) Forward (R) Reverse
(N) Neutral
This lever is used to select forward
or reverse driving. The lever can be
shifted while the tractor is moving
with the clutch disengaged as these
gears are synchromesh. Shifting this
lever frequently can deteriorate the
trans-mission’s life and durability.
Put this lever into the N position
(Neutral) when the tractor is not driv-
en.
TE5O409A
•
Reduce the speed before mov-
ing this lever since it is very
dangerous to switch the driv-
ing direction at a high speed.
CAUTION
MANUAL
CLUTCH PEDAL
Make sure to depress the clutch ped-
al to its end. To start off smoothly, put
the main and range shift levers into
the proper positions and release the
clutch pedal slowly.
t46O524a
(1) Clutch Pedal
MANUAL
te170 (NS4710, NS6010, NS4710H, NS5310H, NS6010H)-���-04.indd 28 2021-03-15 �� 1:54:24
