No. Part Name Quantity Sale code BOM code Remark
1 Front Panel 1 10121111001 2113079189
2 Air Filter 2 10121121202 2113070011
Air cleaner cover 1 10121121203 2113070012
3 Air cleaner holder 1 10121121204 2113070013
Air cleaner 1 10121121205 2113070060
4 Panel frame 1 10121121206 2113079001
5
Front Evaporator ass'y 1 11330113001 2153079053
Rear Evaporator ass'y 1 11330113002 2153079052
6 Bearing holder 2 10121121209 2113070061
7 Left cross flow fan, assy 1 10121121210 2113070059
8 Supporting board for chassis I 1 10121121211 2113070036
9 Strengthening board for chassis 1 10121121212 2123070006
10 Air out frame 1 10121121213 2113070051
11 Holder for cross flow fan 1 10121121214 2113070038
12 Drain Hose 1 10121121215 2110102008
13 Chassis 1 10121121216 2113070035
14 Installation Board 1 10121121217 2123070000
15 Louver motor 1 10121121218 2240020006
16 Horizontal louver, up 1 10121121219 2113070015
17 Horizontal louver, middle 1 10121121220 2113070016
18 Horizontal louver, down 1 10121121221 2113070017
19 Supporting board for chassis II 1 10121121222 2113070037
20 Fan motor 1 10121121223 2240040501
21 Right cross flow fan, assy 1 10121121224 2113070058
22 Indoor temp sensor 1 10118121242 2230131010
23 Clamp for temp sensor 1 10118113003 2113070001
24 Protector for temp sensor 1 10112121224 2113049002
25 Evaporator temp sensor 1 10118121241 2230130002
26 Window cover for repairing 1 10121121225 2113079188
27 E-part box cover 1 10121121226 2113079078
28 Wire joint, 6p 1 10121121227 2230145066
29 Main control board 1 11321111001 2133079046
30 Transformer 1 10118121232 2230099003
31 E-Parts Box 1 10122113005 2113079096
32 Underlay for relay 1 10121121231 2113070032
33 Clip, Capacitor 1 10121121232 2123070007
34 Fan motor capacitor 1 10112121815 2240119014
35 Wire joint, 3p 1 10121121233 2230145027
36 Wire clamp for power cord 1 10121121234 2113070033
37
Display board, Ass'y 1 10121111003 2133079003
Display board enclosure 1 10121121236 2113070034
38 Remote Controller 1 10109111203 2335509005
39 Holder, Remote Controller 1 10109121208 2115501001
40 Copper nut, TLM-B02 1 10909121013 2160032001
41 Copper nut, TLM-D04 1 11324113804 2160032003
To Next Page
