16
EXPLODE VIEW AND PARTS LIST
A01
HANDLE CASE(CASE HANDLE)
36111T3F00 ABS, D-H'S 1ST 1 DWD-HT1011
36111T3F01 HIPS, D-H'S 1 DWD-HB1421
A02 CASE DETERGENT 36111T3G00 D-H'S 1ST ,PP 1 D-HT1011
A03 CAP SOFTENER 3617512000 D-FT'S, F1-F7, PP 1
A04 BOX INLET 3610526500 PP 1
A05 NOZZLE AS
3618103300 PP , NOZZLE T
1
3618112400 PP , NOZZLE U
A06 SCREW TAPPING 7122402011 T2S TRS 4x20 MFZN 1
A08 HOSE INLET 3613276600 EPDM U-TRAP 1
A09 CLAMP HOSE I 3611201400 HSW3, D2.6, MFZN, ID=38 1
A10 HOSE WATER SUPPLY 3613270900 EPDM, ID9.5, OD14.5, L=225 2(3) COLD(+HOT)
A11 CLAMP HOSE 3611205800 100H, ID=13.8 W=10.0 0.9T 4(6) COLD(+HOT)
3615414900 220-240V 2-WAY PP/BRACKET COLD VALVE
A12 VALVE INET 3615414910 220-240V 2WAY NYLON VDE 1
3615416821
220-240V.VDE.BITRON.2WAY + DR TECH
COLD VALVE(EU)
A13 VALVE INLET
3615414800 220-240V,50/60Hz,1WAY
1
HOT VALVE
3615416720
220-240 50/60-1WAY,HOT,BITRON,VDE
HOT VALVE(EU)
A14 SCREW TAPTITE 7272400811 TT3 TRS 4X8 MFZN 2(4) COLD(+HOT)
A15 DECO CASE HANDLE 36116DWL00 ABS, D-H'S 1ST 1 D-HT1011
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
