NO PART CODE PART NAME DESCRIPTION Q'TY REMARK
1 - ASS'Y CAB URT HCFC-141B 1
2 3012500200 GUIDE DRN AL 1
3 4018G54120 PIPE DRN AL T1.0 1
4 3012801000 HEATER GLAS TUBE AS 220V / 148W 1
5 3011408202 COVER HTR *T GALVANIED 1
6 3011408101 COVER HTR *U GALVANIED 1
7 3017044704 EVAPORATOR FIN AS 1 NO ACCUM
8 400EL21214 FUSE TEMP AS SW-103T (77C) 1
9 4017Z90590 FIXTURE FUSE TEMP PP 1
10 3014801230 SENSOR F D AS PTC-KD38-FD2 1
11 3011583400 CUSHION AUX F-PS W50XD55XH190 1
12 3018100010 SWITCH DR 2 BUTTON/4P 1
13 3012906310 HINGE *M AS 1
14 3016004000 SPECIAL BOLT M6XL10 SWCH22A 2
15 3012906100 HINGE *U AS 1
16 3016000600 SPECIAL BOLT M6 X 20 4
17 3012908601 HINGE *T AS 1
18 3016001800 SPECIAL BOLT M6 X 16 3
19 3011429500 COVER *T HI PP 1
20 4017Z40630 ADJ FOOT AS 2
21 3010317510 BASE COMP SAS T1.0 1
22 3010100201 ABSORBER COMP NR H=40 4
23 3956126S50 COMPRESSOR HPL26YH-5N 1
24 4019H09030 SPECIAL WASHER SWRH 4
25 3018104122 SWITCH P RELAY AS 197NHBYY-52 S330 1
26 3816100110 RELAY BAND SUS304 T0.7 1
27 3016801122 DRYER AS HCFC 15G 1
28 3014426400 PIPE WICON AS TSW 1
29 3011118600 CASE VAPORI PP 1
30 3015906230 MOTOR C DRFC 240V/50Hz 1
31 3014392060 PCB MAIN AS DM01 1
32 3018401600 TRANSFORMER POWER 230V/50Hz 1
33 3016401120 CAPACITOR RUN 400VAC/5UF 1
34 3011800640 MOTOR AS 3211DWBFL 240/50 1
35 4017Z42312 FAN ABS 1
36 3013300022 INSULATOR F LUVR AS 1
37 3018900900 LOUVER F M/F AS 1
38 4017Z29010 BRACKET F SENS SPCC 1
39 3017900802 SOCKET F LAMP AS PBT 1
40 3013600020 LAMP AS 240V/15W (E14,CC7A) 3
41 3011443100 COVER F M/F DUCT AS HIPS 1
42 3015500400 WINDOW F GE PC-121R 1
43 3010008910 ASSY M/F DUCT 1
43-1 4010G26030 INSULATOR DAMP B F-PS 1
43-2 4010G26401 R DAMPER AS 1
2) PARTS LIST
AUSTRALIA (NEC, FR-450)
-10-
✔ Caution :
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list.
So, if you need the latest parts information, please refer to PPL (Parts Price List) in Service Information Center
(http://svc.dwe.co.kr)
