Daewoo AGC-5200 RDS User Manual

1 TUNING RANGE MIN KHz 522 522
MAX KHz 1620 1620
2 CHANNEL SPACE KHz KHz 9 9
3 MANUAL - KHz 9 9
4 INTERMEDIATE FREQUENCY ALL KHz 450 450
5 USABLE SENSITIVITY 603 KHz dB 23 35
(S/N = 20dB) 999 KHz dB 23 35
1404 KHz dB 23 35
6 IMAGE REJECTION RATIO 1404 KHz dB 100 40
7 IF REJECTION RATIO 603 KHz dB 80 50
8 SELECTIVITY ( 9 KHz) 999 KHz dB 50 50
9 BAND WIDTH (-6dB) 999 KHz KHz 4~8 5 4
10 S/N RATIO 603 KHz dB 50 40
999 KHz dB 50 40
1404 KHz dB 50 40
11 T.H.D (74dBu) 30% 400Hz 999 KHz % 0.5 3
12 AUDIO FIDELITY(-6dB) 999 KHz Hz 110 120
1KHz 0dBu Ref.(74dBu) KHz 2.2 1.4 K
13 SEARCH STOP LEVEL 603 KHz dB 30 30 10
999 KHz dB 30 30 10
1404 KHz dB 30 30 10
14 LOCAL SEARCH STOP LEVEL 999 KHz dB 20 20
10
15 TWEET MODULATION (2*IF) 900 KHz % 1
1
ELECTRICAL SPECIFICATION
RADIO - AM SECTION
16
NO PERFORMANCE POSITION UNIT NOMINAL LIMIT
