Daewoo AGC-5200 RDS User Manual

5. ELECTRICAL SPECIFICATION
15
NO PERFORMANCE POSITION UNIT NOMINAL LIMIT
RADIO - FM SECTION
1 TUNING RANGE MIN MHz 87.5 87.5
MAX MHz 108.0 108.0
2 CHANNEL SPACE ALL KHz 50 50
3 INTERMEDIATE FREQUENCY ALL MHz 10.7 10.7 0.3
4 USABLE SENSITIVITY 90.1 MHz dB 10 18
(S/N = 30dB) 98.1 MHz dB 10 18
106.1 MHz dB 10 18
5 IMAGE REJECTION RATIO 98.1 MHz dB 70 40
6 IF REJECTION RATIO 98.1 MHz dB 90 50
7 LIMITING SENSITIVITY (-3dB) 98.1 MHz dB 11 12 8
8 AM SUPPRESSION (AM 30%) 98.1MHz dB 45 30
9 S/N RATIO 90.1 MHz dB 52 45
( 60 ) dB INPUT 98.1 MHz dB 52 45
106.1MHz dB 52 45
10 T.H.D 22.5KHz 98.1MHz % 0.3 3
(60) dB INPUT 75KHz 98.1MHz % 0.4 3.5
11 AUDIO LOW 100 Hz dB 0 0 5
FIDELITY HIGH 10 KHz dB -3 -3 5
12 STEREO ON SENSITIVITY 98.1MHz dB 15 20
13 CHANNEL 1KHz/60dBu L-->R dB 30
20
SEPARATION R-->L dB 30
20
1KHz/40dBu L-->R dB 10 20
R-->L dB 10 20
14 SEARCH STOP LEVEL 98.1 MHz dB 20 20 10
15 LOCAL SEARCH STOP LEVEL 98.1 MHz dB 25 20
10
16 MHz dB
17 MHz mV
18 PI SEEK LEVEL 98.5MHz dB 35
19 AF SEARCH LEVEL 98.1MHz dB 35
20 TA POWER(98.1M,45K,60dBu) 98.1MHz mV 200mVrms
21 TP INDICATOR ON LEVEL 98.1MHz dB 35
