98
AUTOMATIC VENTILATOR (OPTION)
Power switch
ҮPressing the power button (1) for
operator of Auto ventilator.
Controller operator switch
ҮPush the suction switch (2, 4) to
open the shutter and intake the out-
door air to the compartment.
ҮPush the exhaust switch (3, 5) to
open the shutter and extract the air
in the compartment to outdoor.
(1EA) (OPTION) (2EA) (OPTION)
1. Power switch
2. Suction switch (REAR)
3. Exhaust switch (REAR)
4. Suction switch (FRONT)
5. Exhaust switch (FRONT)
1. Power switch
2. Suction switch
3. Exhaust switch
To Next Page
