175
TENSION : The suitable tension is less than 10mm when pressed with the thumb.
CRS
W/P
A/C
FAN
7
C/C
ALT
1
3
8
2
1
5
4
6
D1146/Ti,DE08TiS ENGINE
1. Idle pulley
2. Idle pulley
(OPTION : Roof–on cooler)
3. Crank shaft pulley
4. Air compressor pulley
5. Water pump pulley
6. Alternator pulley
7. Fan pulley
8. Cooler compressor pulley
(OPTION : Roof–on cooler)
