Dimensional drawing II
φ
15
170
φ
60
φ
16.5
37
32A/F
6
18
30
60
bar
M12X1.5
M22
X1.5
23
108
63
70
35
4
A
B
3
21

M22X1. 5
6
min13
221–2
min13
1
9
94
24
Legend :
ʨ = Not bored
ʩ = Safety valve
Ports :
1=Energy inlet
21 = Energy outlet
(to reservior)
23 = Energy outlet
(to relief valve)
3=Exhaust
