Air–conditioning cycle
10 10
9
8
7
6
5
4
12
13
2
1
11
33
I. Comp.

1. Compressor
2. Discharge shut–off valve
3. Condenser
4. Receiver tank
5. Service shut–off valve
6. Dryer
7. Sight glass
8. Expansion valve
9. Distributor
10. Evaporator
11. Suction shut–off valve
12. High pressure switch
13. Low pressure switch
