3
CONTROL VIEW
F-CONNECTOR
300 OHM-75 OHM
COUPLING
TRANSFORMER
VHF
75
FROM 75 OHM
VHF ANTENNA WITH
CABLE OR CABLE
TV SYSTEM
REMOCON SENSOR
ENTER
POWER ON/OFF
MENU
CH UP/DN
VOL UP/DN
