Rechargeable Portable Air Cooler & Humidifier
Model No. COL1543
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Before the First Use of Your Portable Air Cooler
Remove all packing materials and discard responsibly.
Ensure all parts are present (if applicable) see Description of Parts below.
Description of Parts
Description of Parts – Control Panel
Description of Parts – Rear Panel
2
1
3
4
5
1. Handle
2. Control Panel
3. Water Tank Cover
4. Steam Outlet x 3
5. Air Outlet/Louver
9
11
12
6
6. Power/Speed Button
7. Humidify Button
8. Light Button
9. LED Indicators
10. Colour Changing/Charge LEDs
11. USB Charging Port
12. Air Inlet
13. USB Charging Cable
14. Micro USB Plug
15. Large USB Plug
13
7
8
14
15
10
