Daewoo DLM Series - DVD Player Connection; Component Cable Connection; S-VHS and RCA Cable Connection

DVD Player
connection
14
INPUT
SERVICE INPUT
COMPONENT
AUDIO PCHDMI
MONITOR OUT
DIGITAL
AUDIO
AV1
VIDEO L - AUDIO - R
L - AUDIO - R
S-VIDEO 1
OPTICAL
INPUT
SERVICE INPUT
COMPONENT
AUDIO PCHDMI
MONITOR OUT
DIGITAL
AUDIO
AV1
VIDEO L - AUDIO - R
L - AUDIO - R
S-VIDEO 1
OPTICAL
BACK OF THE TV SET
BACK OF THE TV SET
Note :
• When you connect with the component video, please check the colour of the cable between the DVD and
TV set.
Note :
If S-video and RCA jack are connected at the same time, the TV set will only detect the S-Video mode.
• If your AV device has both Video OUT terminal and S-Video OUT terminal, the S-Video connection is
recommended for better picture quality.
When connecting with a component cable
When connecting with a S-VHS cable and RCA cable
