To clean a flooded engine
NOTE: if the engine won't start after you have Operated the starter several times, the engine may be
flood with excess fuel. Use following procedure to clear and start a flooded engine.
1.Release the engine start/stop lever to stopengine.
2.Remove the spark plug, dry it, and thenreinstall it.
NOTE: Install the spark plug carefully by hand, to avoid cross-threading.After the plug is seated
tighten 1/8 to 1/4 turn with socket spanner of sparkplug to compress the washer.
1.Pull the engi
ne start/stop lever toward upper handle.
2.Operate the starter as described above
Using the Self-propelled function As shown in Fig 21
This unit equipped with self-propelled system.
If you press the drive lever(clutch lever), the clutch
for the drive will be closed and the lawnmower will
start to move with the engine running .
To stop the moving lawnmower, just simply release
the drive lever in good time.
Mowing
WARNING: Always observe the strictest safety procedures when using the lawnmower. Carefully
read the safety instructions of this manual before using the lawnmower.
WARNING: Never open the ejector flap when the grass bag has been detached (to be emptied) and
the engine is still running. The rotating blade can cause serious injuries!
1. Select your required setting.
2. Start the engine and allow it run, and set it to required speed. See “to start theengine”.
3. Keep a firm grip on the upper handle with engine stop/start lever and drivelever (clutch lever)
closed and walk along with it self-propelling to startmowing.
Working advices
1.
Walk, never run with the mower, be very careful when mowing uneven orrough ground.
2. Mow across slopes, never up and down.
3. Be careful when changing the direction of the mower on a slope.4.Do not mow excessively steep
slopes.
5. The best result will be achieved if the grass is dry. Wet grass will tend to clogthe blade and the
grass collection system.
6. Grass grows at different rates at different time of the year. Never use thelowest cutting height for
the first cut of the season or in drought conditions.
7. Only about o
ne thirds of the grass height should be cut.
8. When mowing with mulching, to ensure that the cut grass can be scatteredefficiently, do not cut
high or wet grass. When you have been cutting forseveral minutes, please stop the mower, and
To clean a flooded engine
NOTE: if the engine won't start after you have Operated the starter several times, the engine may be
flood with excess fuel. Use following procedure to clear and start a flooded engine.
1.Release the engine start/stop lever to stopengine.
2.Remove the spark plug, dry it, and thenreinstall it.
NOTE: Install the spark plug carefully by hand, to avoid cross-threading.After the plug is seated
tighten 1/8 to 1/4 turn with socket spanner of sparkplug to compress the washer.
1.Pull the en
gine start/stop lever toward upper handle.
2.Operate the starter as described above
Using the Self-propelled function As shown in Fig 21
This unit equipped with self-propelled system.
If you press the drive lever(clutch lever), the clutch
for the drive will be closed and the lawnmower will
start to move with the engine running .
To stop the moving lawnmower, just simply release
the drive lever in good time.
Mowing
WARNING: Always observe the strictest safety procedures when using the lawnmower. Carefully
read the safety instructions of this manual before using the lawnmower.
WARNING: Never open the ejector flap when the grass bag has been detached (to be emptied) and
the engine is still running. The rotating blade can cause serious injuries!
1. Select your required setting.
2. Start the engine and allow it run, and set it to required speed. See “to start theengine”.
3. Keep a firm grip on the upper handle with engine stop/start lever and drivelever (clutch lever)
closed and walk along with it self-propelling to startmowing.
Working advices
1. Walk, never run with the mower, be very careful when mowing uneven orrough ground.
2. Mow across slopes, never up and down.
3. Be careful when changing the direction of the mower on a slope.4.Do not mow excessively steep
slopes.
5. The best result will be achieved if the grass is dry. Wet grass will tend to clogthe blade and the
grass collection system.
6. Grass grows at different rates at different time of the year. Never use thelowest cutting height for
the first cut of the season or in drought conditions.
7. Only about one thirds of the grass height should be cut.
8. When mowing with mulching, to ensure that the cut grass can be scatteredefficiently, do not cut
high or wet grass. When you have been cutting forseveral minutes, please stop the mower, and
To clean a flooded engine
NOTE: if the engine won't start after you have Operated the starter several times, the engine may be
flood with excess fuel. Use following procedure to clear and start a flooded engine.
1.Release the engine start/stop lever to stopengine.
2.Remove the spark plug, dry it, and thenreinstall it.
NOTE: Install the spark plug carefully by hand, to avoid cross-threading.After the plug is seated
tighten 1/8 to 1/4 turn with socket spanner of sparkplug to compress the washer.
1.Pull the
engine start/stop lever toward upper handle.
2.Operate the starter as described above
Using the Self-propelled function As shown in Fig 21
This unit equipped with self-propelled system.
If you press the drive lever(clutch lever), the clutch
for the drive will be closed and the lawnmower will
start to move with the engine running .
To stop the moving lawnmower, just simply release
the drive lever in good time.
Mowing
WARNING: Always observe the strictest safety procedures when using the lawnmower. Carefully
read the safety instructions of this manual before using the lawnmower.
WARNING: Never open the ejector flap when the grass bag has been detached (to be emptied) and
the engine is still running. The rotating blade can cause serious injuries!
1. Select your required setting.
2. Start the engine and allow it run, and set it to required speed. See “to start theengine”.
3. Keep a firm grip on the upper handle with engine stop/start lever and drivelever (clutch lever)
closed and walk along with it self-propelling to startmowing.
Working advices
1. Walk, never run with the mower, be very careful when mowing uneven orrough ground.
2. Mow across slopes, never up and down.
3. Be careful when changing the direction of the mower on a slope.4.Do not mow excessively steep
slopes.
5. The best result will be achieved if the grass is dry. Wet grass will tend to clogthe blade and the
grass collection system.
6. Grass grows at different rates at different time of the year. Never use thelowest cutting height for
the first cut of the season or in drought conditions.
7. Only about one thirds of the grass height should be cut.
8. When mowing with mulching, to ensure that the cut grass can be scatteredefficiently, do not cut
high or wet grass. When you have been cutting forseveral minutes, please stop the mower, and
To clean a flooded engine
NOTE: if the engine won't start after you have Operated the starter several times, the engine may be
flood with excess fuel. Use following procedure to clear and start a flooded engine.
1.Release the engine start/stop lever to stopengine.
2.Remove the spark plug, dry it, and thenreinstall it.
NOTE: Install the spark plug carefully by hand, to avoid cross-threading.After the plug is seated
tighten 1/8 to 1/4 turn with socket spanner of sparkplug to compress the washer.
1.Pull the en
gine start/stop lever toward upper handle.
2.Operate the starter as described above
Using the Self-propelled function As shown in Fig 21
This unit equipped with self-propelled system.
If you press the drive lever(clutch lever), the clutch
for the drive will be closed and the lawnmower will
start to move with the engine running .
To stop the moving lawnmower, just simply release
the drive lever in good time.
Mowing
WARNING: Always observe the strictest safety procedures when using the lawnmower. Carefully
read the safety instructions of this manual before using the lawnmower.
WARNING: Never open the ejector flap when the grass bag has been detached (to be emptied) and
the engine is still running. The rotating blade can cause serious injuries!
1. Select your required setting.
2. Start the engine and allow it run, and set it to required speed. See “to start theengine”.
3. Keep a firm grip on the upper handle with engine stop/start lever and drivelever (clutch lever)
closed and walk along with it self-propelling to startmowing.
Working advices
1. Walk, never run with the mower, be very careful when mowing uneven orrough ground.
2. Mow across slopes, never up and down.
3. Be careful when changing the direction of the mower on a slope.4.Do not mow excessively steep
slopes.
5. The best result will be achieved if the grass is dry. Wet grass will tend to clogthe blade and the
grass collection system.
6. Grass grows at different rates at different time of the year. Never use thelowest cutting height for
the first cut of the season or in drought conditions.
7. Only about one thirds of the grass height should be cut.
8. When mowing with mulching, to ensure that the cut grass can be scatteredefficiently, do not cut
high or wet grass. When you have been cutting forseveral minutes, please stop the mower, and
To clean a flooded engine
NOTE: if the engine won't start after you have Operated the starter several times, the engine may be
flood with excess fuel. Use following procedure to clear and start a flooded engine.
1.Release the engine start/stop lever to stopengine.
2.Remove the spark plug, dry it, and thenreinstall it.
NOTE: Install the spark plug carefully by hand, to avoid cross-threading.After the plug is seated
tighten 1/8 to 1/4 turn with socket spanner of sparkplug to compress the washer.
1.Pull the en
gine start/stop lever toward upper handle.
2.Operate the starter as described above
Using the Self-propelled function As shown in Fig 21
This unit equipped with self-propelled system.
If you press the drive lever(clutch lever), the clutch
for the drive will be closed and the lawnmower will
start to move with the engine running .
To stop the moving lawnmower, just simply release
the drive lever in good time.
Mowing
WARNING: Always observe the strictest safety procedures when using the lawnmower. Carefully
read the safet
y instructions of this manual before using the lawnmower.
WARNING: Never open the ejector flap when the grass bag has been detached (to be emptied) and
the engine is still running. The rotating blade can cause serious injuries!
1. Select your required setting.
2. Start the engine and allow it run, and set it to required speed. See “to start theengine”.
3. Keep a firm grip on the upper handle with engine stop/start lever and drivelever (clutch lever)
closed and walk along with it self-propelling to startmowing.
Working adv
ices
1. Walk, never run with the mower, be very careful when mowing uneven orrough ground.
2. Mow across slopes, never up and down.
3. Be careful when changing the direction of the mower on a slope.4.Do not mow excessively steep
slopes.
5. The best result will be achieved if the grass is dry. Wet grass will tend to clogthe blade and the
grass collection system.
6. Grass grows at different rates at different time of the year. Never use thelowest cutting height for
the first cut of the season or in drought conditions.
7. O
nly about one thirds of the grass height should be cut.
8. When mowing with mulching, to ensure that the cut grass can be scatteredefficiently, do not cut
high or wet grass. When you have been cutting forseveral minutes, please stop the mower, and
To clean a flooded engine
NOTE: if the engine won't start after you have Operated the starter several times, the engine may be
flood with excess fuel. Use following procedure to clear and start a flooded engine.
1.Release the engine start/stop lever to stopengine.
2.Remove the spark plug, dry it, and thenreinstall it.
NOTE: Install the spark plug carefully by hand, to avoid cross-threading.After the plug is seated
tighten 1/8 to 1/4 turn with socket spanner of sparkplug to compress the washer.
1.Pull the engi
ne start/stop lever toward upper handle.
2.Operate the starter as described above
Using the Self-propelled function As shown in Fig 21
This unit equipped with self-propelled system.
If you press the drive lever(clutch lever), the clutch
for the drive will be closed and the lawnmower will
start to move with the engine running .
To stop the moving lawnmower, just simply release
the drive lever in good time.
Mowing
WARNING: Always observe the strictest safety procedures when using the lawnmower. Carefully
read the safety instructions of this manual before using the lawnmower.
WARNING: Never open the ejector flap when the grass bag has been detached (to be emptied) and
the engine is still running. The rotating blade can cause serious injuries!
1. Select your required setting.
2. Start the engine and allow it run, and set it to required speed. See “to start theengine”.
3. Keep a firm grip on the upper handle with engine stop/start lever and drivelever (clutch lever)
closed and walk along with it self-propelling to startmowing.
Working advices
1. Wa
lk, never run with the mower, be very careful when mowing uneven orrough ground.
2. Mow across slopes, never up and down.
3. Be careful when changing the direction of the mower on a slope.4.Do not mow excessively steep
slopes.
5. The best result will be achieved if the grass is dry. Wet grass will tend to clogthe blade and the
grass collection system.
6. Grass grows at different rates at different time of the year. Never use thelowest cutting height for
the first cut of the season or in drought conditions.
7. Only about one th
irds of the grass height should be cut.
8. When mowing with mulching, to ensure that the cut grass can be scatteredefficiently, do not cut
high or wet grass. When you have been cutting forseveral minutes, please stop the mower, and
To clean a flooded engine
NOTE: if the engine won't start after you have Operated the starter several times, the engine may be
flood with excess fuel. Use following procedure to clear and start a flooded engine.
1.Release the engine start/stop lever to stopengine.
2.Remove the spark plug, dry it, and thenreinstall it.
NOTE: Install the spark plug carefully by hand, to avoid cross-threading.After the plug is seated
tighten 1/8 to 1/4 turn with socket spanner of sparkplug to compress the washer.
1.Pull the en
gine start/stop lever toward upper handle.
2.Operate the starter as described above
Using the Self-propelled function As shown in Fig 21
This unit equipped with self-propelled system.
If you press the drive lever(clutch lever), the clutch
for the drive will be closed and the lawnmower will
start to move with the engine running .
To stop the moving lawnmower, just simply release
the drive lever in good time.
Mowing
WARNING: Always observe the strictest safety procedures when using the lawnmower. Carefully
read the safety in
structions of this manual before using the lawnmower.
WARNING: Never open the ejector flap when the grass bag has been detached (to be emptied) and
the engine is still running. The rotating blade can cause serious injuries!
1. Select your required setting.
2. Start the engine and allow it run, and set it to required speed. See “to start theengine”.
3. Keep a firm grip on the upper handle with engine stop/start lever and drivelever (clutch lever)
closed and walk along with it self-propelling to startmowing.
Working advi
ces
1. Walk, never run with the mower, be very careful when mowing uneven orrough ground.
2. Mow across slopes, never up and down.
3. Be careful when changing the direction of the mower on a slope.4.Do not mow excessively steep
slopes.
5. The best result will be achieved if the grass is dry. Wet grass will tend to clogthe blade and the
grass collection system.
6. Grass grows at different rates at different time of the year. Never use thelowest cutting height for
the first cut of the season or in drought conditions.
7. On
ly about one thirds of the grass height should be cut.
8. When mowing with mulching, to ensure that the cut grass can be scatteredefficiently, do not cut
high or wet grass. When you have been cutting forseveral minutes, please stop the mower, and
To clean a flooded engine
NOTE: if the engine won't start after you have Operated the starter several times, the engine may be
flood with excess fuel. Use following procedure to clear and start a flooded engine.
1.Release the engine start/stop lever to stopengine.
2.Remove the spark plug, dry it, and thenreinstall it.
NOTE: Install the spark plug carefully by hand, to avoid cross-threading.After the plug is seated
tighten 1/8 to 1/4 turn with socket spanner of sparkplug to compress the washer.
1.Pull the engin
e start/stop lever toward upper handle.
2.Operate the starter as described above
Using the Self-propelled function As shown in Fig 21
This unit equipped with self-propelled system.
If you press the drive lever(clutch lever), the clutch
for the drive will be closed and the lawnmower will
start to move with the engine running .
To stop the moving lawnmower, just simply release
the drive lever in good time.
Mowing
WARNING: Always observe the strictest safety procedures when using the lawnmower. Carefully
read the safety instructions of this manual before using the lawnmower.
WARNING: Never open the ejector flap when the grass bag has been detached (to be emptied) and
the engine is still running. The rotating blade can cause serious injuries!
1. Select your required setting.
2. Start the engine and allow it run, and set it to required speed. See “to start theengine”.
3. Keep a firm grip on the upper handle with engine stop/start lever and drivelever (clutch lever)
closed and walk along with it self-propelling to startmowing.
Working advices
1. W
alk, never run with the mower, be very careful when mowing uneven orrough ground.
2. Mow across slopes, never up and down.
3. Be careful when changing the direction of the mower on a slope.4.Do not mow excessively steep
slopes.
5. The best result will be achieved if the grass is dry. Wet grass will tend to clogthe blade and the
grass collection system.
6. Grass grows at different rates at different time of the year. Never use thelowest cutting height for
the first cut of the season or in drought conditions.
7. Only about one
thirds of the grass height should be cut.
8. When mowing with mulching, to ensure that the cut grass can be scatteredefficiently, do not cut
high or wet grass. When you have been cutting forseveral minutes, please stop the mower, and
www.daewoopower.bg
35
BG
No.
SPARE PARTS LIST ОПИСАНИЕ
1 THE CRANKSHAFT BOX BODY Картер
2 SWINGING ROD Лост на центробежния регулатор
3 PENDULUM STEM SEAL Уплътнение
4 IGNITER Бобина запалване
5 THE FLYWHEEL COMPONENTS Маховик
6 FAN,RECOIL STARTER Вентилатор на маховика
7 COOLING FAN SETTING PLATE Стартов фланец
8 EXHAUST PIPE Тръба отдушник
9 CYLINDER CRANIUM Капак на цилиндровата глава
10 PLATE,BREATHER Клапан отдушник
11 BOLT M4x6 Болт M4x6
12 CRANKCASE COVER Капак на картера
13 CARBURETOR CONNECTION BLOCK Преходен блок на карбуратора
14 CARBURETOR ASSEMBLY Карбуратор
15 BACK TO THE OIL CHAMBER Обратна връзка
16 THE PISTON Бутало
17 PISTON RING ASSEMBLY Сегменти
18 THE PISTON PIN Бутален болт
19 PISTON PIN RETAINER Зегерка бутало
20 THE SPARK PLUG Свещ запалителна
21 OIL GAUGE ASSEMBLY Сонда масло
22 EXTENSION, OIL FILLER Тръба на сондата за масло
23 INLET VALVE Всмукателен клапан
24 VALVE OIL SEAL Маслообирач на клапаните
25 INLET VALVE SPRING SEAT Седло на пружината на клапана
26 AIR FILTER ELEMENT Въздушен филтър
27 CENTRIFUGAL GOVERNOR GEAR ASSEMBLY Центробежен регулатор
28 CONNECTING ROD COMPONENT Биела
29 NUT M12x1.25 Гайка M12x1.25
30 BOLT M6X16 Болт M6X16
31 BOLT M6X25 Болт M6X25
32 BOLT M8X45 Болт M8X45
33 STUD M6X92 Шпилка M6X92
34 AIR FILTER GASKET Гарнитура на въздушния филтър
35 INTAKE GASKET Гарнитура вход цилиндър
36 CARBURETOR GASKET Гарнитура карбуратор
37 THE EXHAUST VALVE Изпускателен клапан
38 VALVE SPRINGS Пружини на клапаните
39 THE VALVE LIFTER Повдигач на клапана
40 THE VALVE PUSH ROD Лост на повдигача на клапана
41 THE CRANKSHAFT Колянов вал
To Next Page
Loading...
