clean the blade and the deck.
9. Do not remove grass debris in the mower casing or on the blade by hand orwith your feet. Instead
use suitable tools such as a brush or broom.
Emptying the grass bag
As soon as grass clippings start to trail the lawn mower, it is time to empty the
grass bag.
NOTE: Before taking off the grass bag, switch off the engine and wait untilthe blade has come to a
stop.
1. To take off the grass bag, use one hand to lift up ejector flap and the other to grab onto the carry
handle. The ejector flap automatically
falls down after removing the grass bag and closes off the
rear chute opening.
2. Empty the grass debris in the grass bag, and refit grass Bag.
NOTE: If any grass residue is caught in the discharge chute, clean it using a brush. Do not remove
grass debris in the mower casing or on the blade by hand or with your feet. Instead use suitable
tools such as a brush or broom. To ensure that the cut grass can be collected into grass Bag, the
discharge opening and inside the mower casing must be cleared of any blockage.
10. STORING AND MAI
NTENANCE
WARNING : Before performing any maintenance or cleaning work, switch Off the engine and wait
until the blade has come to a stop.
Cleaning
General cleaning
The lawn mower should be cleaned thoroughly every time after it has been used. Always clean your
lawnmower immediately after use. Do not allow grass cuttings and other debris to become dry and
hard on any of the mower surfaces. Dried grass remnants and dirt may impair the mowing opera-
tion. Check that the grass chute is free of any residual grass. Remove
any such residue. Check the
underside of the lawn mower and the blade mount. for this purpose ,tilt the Lawn mower onto its left
side (opposite the oil filler neck)
NOTE: Before placing the lawn mower on its side , fully drain the fuel tank using a petrol extraction
pump. Do not tilt the lawn mower by more than 90 degrees.
Maintenance of the spark plug.
As shown in Fig 22
1. Once the engine has cooled, pull off the spark plugwith a twist.
2. Remove the spark plug using a spark plug wrench3.Clean the spark plug with a wire brush (not
supp
lied ).4.Using a feeler gauge set the gap to 0.75mm
5. Install the spark plug carefully by hand to avoid cross-threading.
6. After the spark plug is seated tighten with thespanner to compress the washer.
How to Service the Air Filter As shown in Fig 23Soiled air filters reduce the engine output by supply
too little air to the carburetor. if the air contains a lot of dust , the air filter should be checked more
frequently.
clean the blade and the deck.
9. Do not remove grass debris in the mower casing or on the blade by hand orwith your feet. Instead
use suitable tools such as a brush or broom.
Emptying the grass bag
As soon as grass clippings start to trail the lawn mower, it is time to empty the
grass bag.
NOTE: Before taking off the grass bag, switch off the engine and wait untilthe blade has come to a
stop.
1. To take off the grass bag, use one hand to lift up ejector flap and the other to grab onto the carry
handle. The ejector flap automaticall
y falls down after removing the grass bag and closes off the
rear chute opening.
2. Empty the grass debris in the grass bag, and refit grass Bag.
NOTE: If any grass residue is caught in the discharge chute, clean it using a brush. Do not remove
grass debris in the mower casing or on the blade by hand or with your feet. Instead use suitable
tools such as a brush or broom. To ensure that the cut grass can be collected into grass Bag, the
discharge opening and inside the mower casing must be cleared of any blockage.
10. STORING AND MAI
NTENANCE
WARNING : Before performing any maintenance or cleaning work, switch Off the engine and wait
until the blade has come to a stop.
Cleaning
General cleaning
The lawn mower should be cleaned thoroughly every time after it has been used. Always clean your
lawnmower immediately after use. Do not allow grass cuttings and other debris to become dry and
hard on any of the mower surfaces. Dried grass remnants and dirt may impair the mowing opera-
tion. Check that the grass chute is free of any residual grass. Remove
any such residue. Check the
underside of the lawn mower and the blade mount. for this purpose ,tilt the Lawn mower onto its left
side (opposite the oil filler neck)
NOTE: Before placing the lawn mower on its side , fully drain the fuel tank using a petrol extraction
pump. Do not tilt the lawn mower by more than 90 degrees.
Maintenance of the spark plug.
As shown in Fig 22
1. Once the engine has cooled, pull off the spark plugwith a twist.
2. Remove the spark plug using a spark plug wrench3.Clean the spark plug with a wire brush (not
s
upplied ).4.Using a feeler gauge set the gap to 0.75mm
5. Install the spark plug carefully by hand to avoid cross-threading.
6. After the spark plug is seated tighten with thespanner to compress the washer.
How to Service the Air Filter As shown in Fig 23Soiled air filters reduce the engine output by supply
too little air to the carburetor. if the air contains a lot of dust , the air filter should be checked more
frequently.
clean the blade and the deck.
9. Do not remove grass debris in the mower casing or on the blade by hand orwith your feet. Instead
use suitable tools such as a brush or broom.
Emptying the grass bag
As soon as grass clippings start to trail the lawn mower, it is time to empty the
grass bag.
NOTE: Before taking off the grass bag, switch off the engine and wait untilthe blade has come to a
stop.
1. To take off the grass bag, use one hand to lift up ejector flap and the other to grab onto the carry
handle. The ejector flap automatical
ly falls down after removing the grass bag and closes off the
rear chute opening.
2. Empty the grass debris in the grass bag, and refit grass Bag.
NOTE: If any grass residue is caught in the discharge chute, clean it using a brush. Do not remove
grass debris in the mower casing or on the blade by hand or with your feet. Instead use suitable
tools such as a brush or broom. To ensure that the cut grass can be collected into grass Bag, the
discharge opening and inside the mower casing must be cleared of any blockage.
10. STORING AND MA
INTENANCE
WARNING : Before performing any maintenance or cleaning work, switch Off the engine and wait
until the blade has come to a stop.
Cleaning
General cleaning
The lawn mower should be cleaned thoroughly every time after it has been used. Always clean your
lawnmower immediately after use. Do not allow grass cuttings and other debris to become dry and
hard on any of the mower surfaces. Dried grass remnants and dirt may impair the mowing opera-
tion. Check that the grass chute is free of any residual grass. Remo
ve any such residue. Check the
underside of the lawn mower and the blade mount. for this purpose ,tilt the Lawn mower onto its left
side (opposite the oil filler neck)
NOTE: Before placing the lawn mower on its side , fully drain the fuel tank using a petrol extraction
pump. Do not tilt the lawn mower by more than 90 degrees.
Maintenance of the spark plug.
As shown in Fig 22
1. Once the engine has cooled, pull off the spark plugwith a twist.
2. Remove the spark plug using a spark plug wrench3.Clean the spark plug with a wire brush (not
s
upplied ).4.Using a feeler gauge set the gap to 0.75mm
5. Install the spark plug carefully by hand to avoid cross-threading.
6. After the spark plug is seated tighten with thespanner to compress the washer.
How to Service the Air Filter As shown in Fig 23Soiled air filters reduce the engine output by supply
too little air to the carburetor. if the air contains a lot of dust , the air filter should be checked more
frequently.
WARNING
1. Remove the air cleaner outside cover (A). Be carefulto prevent dirt and debris from falling int
o the
aircleaner assembly.
2. Separate the Air Filter (A) from the Air Filter Housing (B).
3.Inspect the air filter. Clean dirty air filter with warmwater and mild soap. Allow air filter to dry
thoroughly before re-installation4.Install the air filter assembly onto the carburetor and secure with
screw.
Note: Do not use pressurized air or solvents to clean the filter. Pressurized air can damage the filter
and solvents will dissolve the filter.
Changing the engine oil Tilt the lawnmower towards the oil filler, have a container ready to catch the
oil and remove the dipstick. Once the oil has been emptied, replace the dipstick and wipe clean any
spillages. Refill with 500ml SAE30 oil or equivalent, i. e. SAE 5W/30, SAE10W/30.
Refill with 500ml SAE30 oil or equivalent i. e SAE5W/30, SAE10W/30. When the dipstick is rested on
the filler pipe (i. e . not turn in pace ), the oil level must be between the min and max marks on the
dipstick.
See “Checking the engine oil level and filling with engine oil” Start the engine and allow it to run
briefly.
Stop the e
ngine, wait one minute and check the oil level. Top up if necessary. Note! see more in
engine manual.
Replacing the blade
For safety reasons you should only ever have your blade sharpened, balanced and mounted by an
authorised service workshop. For optimum results it is recommended that the blade should be
inspected once a year.
WARNING! Before you remove the grass collection bag, stop the engine and wait until the blade
stops completely.
WARNING! You will need garden gloves (not provided) and a spanner wrench(not pr
ovided) to
remove the blade.
NOTE! Don't invert the mower. Tip it slightly towards the oil filler pipe and reach under the deck.
WARNING! Always handle the blade with care, sharp edges could cause injury USE GLOVES. Renew
your metal blade after 50Hrs mowing or 2yrs whichever is sooner regardless of condition.
clean the blade and the deck.
9. Do not remove grass debris in the mower casing or on the blade by hand orwith your feet. Instead
use suitable tools such as a brush or broom.
Emptying the grass bag
As soon as grass clippings start to trail the lawn mower, it is time to empty the
grass bag.
NOTE: Before taking off the grass bag, switch off the engine and wait untilthe blade has come to a
stop.
1. To take off the grass bag, use one hand to lift up ejector flap and the other to grab onto the carry
handle. The ejector flap automatically
falls down after removing the grass bag and closes off the
rear chute opening.
2. Empty the grass debris in the grass bag, and refit grass Bag.
NOTE: If any grass residue is caught in the discharge chute, clean it using a brush. Do not remove
grass debris in the mower casing or on the blade by hand or with your feet. Instead use suitable
tools such as a brush or broom. To ensure that the cut grass can be collected into grass Bag, the
discharge opening and inside the mower casing must be cleared of any blockage.
10. STORING AND MAINTEN
ANCE
WARNING : Before performing any maintenance or cleaning work, switch Off the engine and wait
until the blade has come to a stop.
Cleaning
General cleaning
The lawn mower should be cleaned thoroughly every time after it has been used. Always clean your
lawnmower immediately after use. Do not allow grass cuttings and other debris to become dry and
hard on any of the mower surfaces. Dried grass remnants and dirt may impair the mowing opera-
tion. Check that the grass chute is free of any residual grass. Remove any su
ch residue. Check the
underside of the lawn mower and the blade mount. for this purpose ,tilt the Lawn mower onto its left
side (opposite the oil filler neck)
NOTE: Before placing the lawn mower on its side , fully drain the fuel tank using a petrol extraction
pump. Do not tilt the lawn mower by more than 90 degrees.
Maintenance of the spark plug.
As shown in Fig 22
1. Once the engine has cooled, pull off the spark plugwith a twist.
2. Remove the spark plug using a spark plug wrench3.Clean the spark plug with a wire brush (not
supplie
d ).4.Using a feeler gauge set the gap to 0.75mm
5. Install the spark plug carefully by hand to avoid cross-threading.
6. After the spark plug is seated tighten with thespanner to compress the washer.
How to Service the Air Filter As shown in Fig 23Soiled air filters reduce the engine output by supply
too little air to the carburetor. if the air contains a lot of dust , the air filter should be checked more
frequently.
clean the blade and the deck.
9. Do not remove grass debris in the mower casing or on the blade by hand orwith your feet. Instead
use suitable tools such as a brush or broom.
Emptying the grass bag
As soon as grass clippings start to trail the lawn mower, it is time to empty the
grass bag.
NOTE: Before taking off the grass bag, switch off the engine and wait untilthe blade has come to a
stop.
1. To take off the grass bag, use one hand to lift up ejector flap and the other to grab onto the carry
handle. The ejector flap automatically fal
ls down after removing the grass bag and closes off the
rear chute opening.
2. Empty the grass debris in the grass bag, and refit grass Bag.
NOTE: If any grass residue is caught in the discharge chute, clean it using a brush. Do not remove
grass debris in the mower casing or on the blade by hand or with your feet. Instead use suitable
tools such as a brush or broom. To ensure that the cut grass can be collected into grass Bag, the
discharge opening and inside the mower casing must be cleared of any blockage.
10. STORING AND MAINTENA
NCE
WARNING : Before performing any maintenance or cleaning work, switch Off the engine and wait
until the blade has come to a stop.
Cleaning
General cleaning
The lawn mower should be cleaned thoroughly every time after it has been used. Always clean your
lawnmower immediately after use. Do not allow grass cuttings and other debris to become dry and
hard on any of the mower surfaces. Dried grass remnants and dirt may impair the mowing opera-
tion. Check that the grass chute is free of any residual grass. Remove any
such residue. Check the
underside of the lawn mower and the blade mount. for this purpose ,tilt the Lawn mower onto its left
side (opposite the oil filler neck)
NOTE: Before placing the lawn mower on its side , fully drain the fuel tank using a petrol extraction
pump. Do not tilt the lawn mower by more than 90 degrees.
Maintenance of the spark plug.
As shown in Fig 22
1. Once the engine has cooled, pull off the spark plugwith a twist.
2. Remove the spark plug using a spark plug wrench3.Clean the spark plug with a wire brush (not
s
upplied ).4.Using a feeler gauge set the gap to 0.75mm
5. Install the spark plug carefully by hand to avoid cross-threading.
6. After the spark plug is seated tighten with thespanner to compress the washer.
How to Service the Air Filter As shown in Fig 23Soiled air filters reduce the engine output by supply
too little air to the carburetor. if the air contains a lot of dust , the air filter should be checked more
frequently.
clean the blade and the deck.
9. Do not remove grass debris in the mower casing or on the blade by hand orwith your feet. Instead
use suitable tools such as a brush or broom.
Emptying the grass bag
As soon as grass clippings start to trail the lawn mower, it is time to empty the
grass bag.
NOTE: Before taking off the grass bag, switch off the engine and wait untilthe blade has come to a
stop.
1. To take off the grass bag, use one hand to lift up ejector flap and the other to grab onto the carry
handle. The ejector flap automaticall
y falls down after removing the grass bag and closes off the
rear chute opening.
2. Empty the grass debris in the grass bag, and refit grass Bag.
NOTE: If any grass residue is caught in the discharge chute, clean it using a brush. Do not remove
grass debris in the mower casing or on the blade by hand or with your feet. Instead use suitable
tools such as a brush or broom. To ensure that the cut grass can be collected into grass Bag, the
discharge opening and inside the mower casing must be cleared of any blockage.
10. STORING AND MAINTE
NANCE
WARNING : Before performing any maintenance or cleaning work, switch Off the engine and wait
until the blade has come to a stop.
Cleaning
General cleaning
The lawn mower should be cleaned thoroughly every time after it has been used. Always clean your
lawnmower immediately after use. Do not allow grass cuttings and other debris to become dry and
hard on any of the mower surfaces. Dried grass remnants and dirt may impair the mowing opera-
tion. Check that the grass chute is free of any residual grass. Remove an
y such residue. Check the
underside of the lawn mower and the blade mount. for this purpose ,tilt the Lawn mower onto its left
side (opposite the oil filler neck)
NOTE: Before placing the lawn mower on its side , fully drain the fuel tank using a petrol extraction
pump. Do not tilt the lawn mower by more than 90 degrees.
Maintenance of the spark plug.
As shown in Fig 22
1. Once the engine has cooled, pull off the spark plugwith a twist.
2. Remove the spark plug using a spark plug wrench3.Clean the spark plug with a wire brush (not
s
upplied ).4.Using a feeler gauge set the gap to 0.75mm
5. Install the spark plug carefully by hand to avoid cross-threading.
6. After the spark plug is seated tighten with thespanner to compress the washer.
How to Service the Air Filter As shown in Fig 23Soiled air filters reduce the engine output by supply
too little air to the carburetor. if the air contains a lot of dust , the air filter should be checked more
frequently.
clean the blade and the deck.
9. Do not remove grass debris in the mower casing or on the blade by hand orwith your feet. Instead
use suitable tools such as a brush or broom.
Emptying the grass bag
As soon as grass clippings start to trail the lawn mower, it is time to empty the
grass bag.
NOTE: Before taking off the grass bag, switch off the engine and wait untilthe blade has come to a
stop.
1. To take off the grass bag, use one hand to lift up ejector flap and the other to grab onto the carry
handle. The ejector flap automatically fall
s down after removing the grass bag and closes off the
rear chute opening.
2. Empty the grass debris in the grass bag, and refit grass Bag.
NOTE: If any grass residue is caught in the discharge chute, clean it using a brush. Do not remove
grass debris in the mower casing or on the blade by hand or with your feet. Instead use suitable
tools such as a brush or broom. To ensure that the cut grass can be collected into grass Bag, the
discharge opening and inside the mower casing must be cleared of any blockage.
10. STORING AND MAINTENAN
CE
WARNING : Before performing any maintenance or cleaning work, switch Off the engine and wait
until the blade has come to a stop.
Cleaning
General cleaning
The lawn mower should be cleaned thoroughly every time after it has been used. Always clean your
lawnmower immediately after use. Do not allow grass cuttings and other debris to become dry and
hard on any of the mower surfaces. Dried grass remnants and dirt may impair the mowing opera-
tion. Check that the grass chute is free of any residual grass. Remove any
such residue. Check the
underside of the lawn mower and the blade mount. for this purpose ,tilt the Lawn mower onto its left
side (opposite the oil filler neck)
NOTE: Before placing the lawn mower on its side , fully drain the fuel tank using a petrol extraction
pump. Do not tilt the lawn mower by more than 90 degrees.
Maintenance of the spark plug.
As shown in Fig 22
1. Once the engine has cooled, pull off the spark plugwith a twist.
2. Remove the spark plug using a spark plug wrench3.Clean the spark plug with a wire brush (not
sup
plied ).4.Using a feeler gauge set the gap to 0.75mm
5. Install the spark plug carefully by hand to avoid cross-threading.
6. After the spark plug is seated tighten with thespanner to compress the washer.
How to Service the Air Filter As shown in Fig 23Soiled air filters reduce the engine output by supply
too little air to the carburetor. if the air contains a lot of dust , the air filter should be checked more
frequently.
clean the blade and the deck.
9. Do not remove grass debris in the mower casing or on the blade by hand orwith your feet. Instead
use suitable tools such as a brush or broom.
Emptying the grass bag
As soon as grass clippings start to trail the lawn mower, it is time to empty the
grass bag.
NOTE: Before taking off the grass bag, switch off the engine and wait untilthe blade has come to a
stop.
1. To take off the grass bag, use one hand to lift up ejector flap and the other to grab onto the carry
handle. The ejector flap automatically
falls down after removing the grass bag and closes off the
rear chute opening.
2. Empty the grass debris in the grass bag, and refit grass Bag.
NOTE: If any grass residue is caught in the discharge chute, clean it using a brush. Do not remove
grass debris in the mower casing or on the blade by hand or with your feet. Instead use suitable
tools such as a brush or broom. To ensure that the cut grass can be collected into grass Bag, the
discharge opening and inside the mower casing must be cleared of any blockage.
10. STORING AND MAINTE
NANCE
WARNING : Before performing any maintenance or cleaning work, switch Off the engine and wait
until the blade has come to a stop.
Cleaning
General cleaning
The lawn mower should be cleaned thoroughly every time after it has been used. Always clean your
lawnmower immediately after use. Do not allow grass cuttings and other debris to become dry and
hard on any of the mower surfaces. Dried grass remnants and dirt may impair the mowing opera-
tion. Check that the grass chute is free of any residual grass. Remove any
such residue. Check the
underside of the lawn mower and the blade mount. for this purpose ,tilt the Lawn mower onto its left
side (opposite the oil filler neck)
NOTE: Before placing the lawn mower on its side , fully drain the fuel tank using a petrol extraction
pump. Do not tilt the lawn mower by more than 90 degrees.
Maintenance of the spark plug.
As shown in Fig 22
1. Once the engine has cooled, pull off the spark plugwith a twist.
2. Remove the spark plug using a spark plug wrench3.Clean the spark plug with a wire brush (not
sup
plied ).4.Using a feeler gauge set the gap to 0.75mm
5. Install the spark plug carefully by hand to avoid cross-threading.
6. After the spark plug is seated tighten with thespanner to compress the washer.
How to Service the Air Filter As shown in Fig 23Soiled air filters reduce the engine output by supply
too little air to the carburetor. if the air contains a lot of dust , the air filter should be checked more
frequently.
www.daewoopower.bg
36
BG
No.
SPARE PARTS LIST ОПИСАНИЕ
42 FLAT WASHER Плоска шайба
43 POSITIONING PIN OF CRANKCASE Щифт фиксиращ
44 GASKET,CYLINDER HEAD Гарнитура цилиндрова глава
45 CYLINDER HEAD Цилиндрова глава
46 THE CRANKSHAFT OIL SEAL Семеринг колянов вал долен
47 THE CRANKSHAFT OIL SEAL Семеринг колянов вал горен
48 CRANKSHAFT TIMING DRIVING GEAR Зъбна предавка на коляновия вал
49 FUEL PIPE Маркуч резервоар
50 FUEL PIPE CLAMP Ф10 Скоба маркуч резервоар Ф10
51 SPEED REGULATING SPRING B Пружина регулираща
52 CONTROL ARM Регулиращо рамо
53 THE BRAKE COMPONENTS Спирачка маховик
54 BRAKE SPRING Пружина спирачна
55 FLAMEOUT WIRE Кабел гасене на двигателя
56 SPEED CONTROL CONTROLLER Фиксираща планка
57 CAMSHAFT ASSEMBLY Разпределителен вал
58 MUFFLER Ауспух
59 ROCKER ARM Балансьор на клапана
60 THE THROTTLE LEVER Лост на газта
61 THE FUEL TANK Резервоар
62 THE CAP Капачка резервоар
63 CHECK BACK CLIP Шплент
64 PIN, ARM, ROCKER Щифт на балансьора
65 WIND SHIELD,RH Планка на спирачката 1
66 WIND SHIELD,RH Планка на спирачката 2
67 IN THE HOOD Капак на двигателя
68 HOOD,FAN Стартер
69 BOLT M4.2*16 Болт M4.2*16
70 PACKING,EXHAUST Гарнитура ауспух
71 BOLT M6*10 Болт M6*10
72 FLAT WASHER Плоска шайба
73 NUT M6 Гайка M6
74 TUBE Маркуч карбуратор
75 STUD Шпилка
76 NUT M6 Гайка М6
77 MUFFLER HOUSING Предпазител на ауспуха
78 BOLT M6*22 Болт M6*22
79 FILTER Филтър резервоар
To Next Page
Loading...
