NOTE: When use side discharge function. First need remove the grass
Bag and plug the mulching plug.
1. Lift the side discharge cover with
One hand and hook in the side dischargeDuct with the other hand.
2. Release the side discharge cover tosecure the duct in position.
Assembling the cup holder (optional)
As shown in Fig 13
1. Take out the plastic panel (1) from the box.
2. Align the mounting holes on the plastic panel
with the mounting holes on the upper-handle (2).
3. Fix the plastic panel with the bolts
and nuts (3) and (4) provided.
Checkin
g the engine oil level And filling with engine
oil As shown in Fig 15-16
CAUTION! The following procedures and adjustments
must be performed before the engine is started.
Do not attempt to make any of these adjustments
while the engine is running.
CAUTION! To prevent engine damage the engine is
shipped without oil or petrol. The engine must be filled
with the correct grade of oil and petrol before
starting the engine.
NOTE! Running the engine with a low oil level will cause engine damage. It is recommend that high
detergent, p
remium quality 4-stroke engine oil used.
CAUTION! Always use high quality detergent oil classified SAE30 oil (or equivalent e. g SAE 10W/30,
often termed as 4 Stroke lawn mower oil. Never use additives with recommended oil. To prolong the
life of your engine it is important that the oil is changed after the first 20 hours of use.
NOTE: To check the engine oil level, stop engine and place the mower on a level surface.
1.Remove the oil filler dipstick and wipe
oil from it with a clean cloth.
2. Insert the dipstick into the oil filler neck,3. Then remove the dipstick and check the oillevel. the oil
level must be between theMin and Max marks on the dipstick. If nearthe lower level, fill to upper
lever with the recommended oil((or equivalent t e. g SAE 10W/30). Do not overfill.
