7. STORAGE
Store the mower in a cool, clean, dry place.
Preparing the Mower for Storage
A WARNING
Gasoline vapors can explode.
• Do not store the mower in an enclosure near an open ame.
• Allow the engine to cool before storing it.
4. Always add fuel atabilizer to the fuel as directed by the fuel stabilizer
manufacturer.
Remove spark plug and spray a light fog of penetrating oil, such as
WD-40 into the spark plug hole; Then pull the starter rope
5. Remove spark plug and spray a light fog of penetrating
oil, such as WD-40 into the spark plug hole; Then pull the starter rope.
6. Install the spark plug and tighten it with a wrench to 15 ft-lb (20 N-m).
7. Tighten all nuts, bolts, and screws.
8. Leave spark plug cable disconnected.
8. TECHNICAL DATA
Drive type: Hand push
Cutting heights: 25-75 mm with 5 grades
Height adjustment: Centre adjustment
Cutting width: 510 mm(20”)
Blade: Straight blade
Deck material: steel
Front/Rear wheel: 7/11 inch K
Wheel materials(pp/pp+pvc): PP+PVC
Soft grip on the handle: Yes
Catching type: Side discharge/Mulching
ENGINE
Displacement (cc): 173 cc
Engine Model: DV170
Starting System: Recoil
Power MAX(kw): 3.0 kW
Rated speed: 2800 rpm
