8
Figure 1
cables to the outside of the handle as you install the handle.
1. Handle knob (2)
2. Move the handle to the operating position.
3. Install and tighten the handle knobs that you removed in step 1. (Fi-
gure 1)
2. Attaching Wheels (See Figure 2)
• Parts needed - 2 front wheels (7”), 2 rear wheels (11”), 4 washers and
4 nuts.
• Install the washer into wheel axle then put on the wheel into wheel
axle.
• Screw lock nut into the end of the thread of the wheel axle until it
locks into place.
• Then place wheel cover by tapping it in.
• Repeat process on the other side of the lawn mower to install the
To Next Page
