• Turn left and move towards position 4
• Repeat the above procedures as required.
WARNING! Do not work towards the cable.
Blade maintenance (g.5)
• Regularly remove grass and dirt from the blade.
• At the beginning of the gardening season, carefully examine the con-
dition of the blade.
• If the blade is very blunt, sharpen or replace the blade.
• If the blade is damaged or worn, t a new blade.
If the blade is slipping, put the screwdriver into the location hole, tighten
the blade by wrench. see g.6 and g.7
WARNING! Observe the following precautions:
• Disconnect the mower from the mains and wait until the blade has
stopped rotating before proceeding.
• Be careful not to cut yourself. Use heavy-duty gloves or a cloth to grip
the blade.
• Only use the specied replacement blade.
• Do not remove the impeller (A)for any reason.
To replace the blade:
• Turn the mower onto its side.
13
