Daewoo DSA-099L User Manual

Exploded Views and Parts List
Outdoor unit
2020
DSA-099L DSA-129L
No. Part Name Quantity Item Code
1. Air outlet grille 1 KFR20W.1.1-2
2 Front panel 1 KFR20W.1.1-1
3 Left handle 1 SL05-01
4 Top panel 1 KFR20W.1.2-1
5 Fan screw nut M6 (left revolve) 1 GB41-86
6 Outdoor fan 1 KFR20W.1.5.1
7 Outdoor fan motor 1 DQ01-09B
8 Outdoor fan motor supporter 1 KFR20W.1.5-1
9 Condenser 1 KF23W.2.1A(A1-GB42)
10 right Left back side board 1 KFR20W.1.1-3
11 Electrical install board supporter 1 KFR20W.3.2-2
12 Left back side board 1 KFR20W.1.2-2
13 Back cover 1 KFR20W.1.2-9
14 right Left back side board 1 KFR20W.1.1-3
15 Electrical install board supporter 1 KFR33W.3.2-1
16 Capacitor fixer 1 BJ06-01
17 Outdoor unit terminal block 1 DQ12-11
18 power supply cord clip 1 SL01-04
19 Compressor capacitor 1 DQ11-57
20 Fan motor capacitor 1 DQ11-05
21 Capillary 1 AU-09C63F42a04.2.2
22 Capillary 1 AU-09C63F42a04.2.1
23 1/4 on-off valve 1 DG03-12
24 3/8 on-off valve 1 DG03-02
25 valve board 1 KFR35W.1.3-3
26 Compressor 1 AU-09C63F42a04.2.4.1
27 Inspiration pipe assembly 1 AU-09C63F42a04.2.3
28 Compressor screw 1 LD06-01
29 Back board 1 KFR25W.1.4C(G1-4)/6
30 Right handle 1 SL05-02
