No. Part Name Quantity Item Code
1. Connecting board of mounting plate 1 KFR36G.9-2(D9-130)
2 Mounting plate 2 KFR36G.9-1(D9-130)
3 Pipe fixing plate 1 1 KFR36G.8-2(D9-130)
4 Bottom shell 1 KFR36G.8-1(D9-130)
5 Indoor fan 1 KFR36G.7-2(D9-130)
6 Motor box cover 1 KFR36G.7-1(D9-130)
7 Stepping motor 1 DQ04-03A
8 Indoor fan motor 1 DQ02-17A
9 Cable fixing board 1 KFR33G.3.1 -7
10 Indoor unit terminal block 1 DQ12-54
11 Transformer 1 DQ16-24A
12 Room coil pipe temperature sensor 1 DQ13-54
13 Room temperature sensor 1 DQ13-60.
14 Power supply cord clip 1
KFR51L.1.2-6 G1-4
15 Control PCB assem bly 1 KF48G.3.1(D18-120)
16 Power supply cord 1 DQ05-102
17 Electrical apparatus box 1 KFR36G.3-1(D9-130)
18 Electrical apparatus box cover 2 KFR36G.3-2(D9-130)
19 Air filter holder 2 KFR36G.17-1(D9-130)
20 Panel body 1 KFR36G.2-1(D9-130)
21 display assembly 1 KF48G.2.1-3(D18-120)
22 Control box 1 KF48G.2.1-1(D18-120)
23 display assembly 1 KF48G.2.1-2(D18-120)
24 Panel 1 KF48G.1-1(D18-120)
25 Air filter 2 KFR36G.2.1( D9-130)
26 Evaporator 1 KFR36G.4(D9-130)
27 Deflector packing sleeve 6 KFR36G.6.3 -3(D9-130)
28 Water collecting tray 1 KF25G.1 -2(L1-130)
29 Left hand vertical vane 1 KF25G.2.1-2(L1-130)
30 Bottom deflector assembly KFR36G.6.3-1(D9-130)
31 Upper deflector assembly KFR36G.6.3-2(D9-130)
32 Right hand vertical vane 1 KFR36G.6.1(D9-130)
33 Drain hose assembly 1 SL07-01
34 Oil bearing 1 XJ04-01
35 Srew cover 3 KFR36G.2-2(D9-130)
36 Pipe fixing plate 2 1 KFR36G.8-3(D9-130)
