MAIN ELECTRIC PARTS
¡ DSA-101L
¡ DSA-121L
PART NAME PART CODE SPEC. QUANTITY REMARK
Fan Motor 3108001220 IC-8428DWKG7C 1
Fan Motor Capacitor 3106900300 1.0uF 400VAC 1
Fuse 5FVLB3152L 250V 3.15A 1
Transformer 5EPV050100 220V/18V 1
Stepping Motor 3108000100 MP28GA (L=400mm) 1
Terminal Block 3108912300 SN-DBW-03P 1
Compressor 3100030EE0 RCA100A001 1
Fan Motor 3108003010 IC-9630DWLA6B 1
Dual Capacitor 3109502100 2.0+25µF 400VAC 1
Terminal Block 3108912300 SN-DBW-03P 1
Indoor
Unit
Outdoor
Unit
Indoor
Unit
Outdoor
Unit
PART NAME PART CODE SPEC. QUANTITY REMARK
Fan Motor 3108001220 IC-8428DWKG7C 1
Fan Motor Capacitor 3106900300 1.0uF 400VAC 1
Fuse 5FVLB3152L 250V 3.15A 1
Transformer 5EPV050100 220V/18V 1
Stepping Motor 3108000100 MP28GA (L=400mm) 1
Terminal Block 3108912300 SN-DBW-03P 1
Compressor 3100030DE0 RCA120A001 1
Fan Motor 3108003010 IC-9630DWLA6B 1
Dual Capacitor 3109502000 2.0+30µF 400VAC 1
Terminal Block 3108912300 SN-DBW-03P 1
