¡ DSA-101L/DSA-121L PART LIST(INDOOR UNIT)
No PART CODE PART NAME Q'TY SPEC REMARK
1 3100400201 BODY 1 ABS or HIPS
2 3108001220 MOTOR IDU 1 220V 50/60Hz
3 3101500400 CUSHION MOTOR 2 CR
4 3106400200 BEARING PLASTIC ASS'Y 1
5 3100014400 FAN CROSS FLOW ASS'Y 1 SAN+G. F20%
6 7485401012 SET SCREW 1 6S-4 X 10-E
7 3100014300 EVAPORATOR ASS'Y 1
8 3108100401 PAN DRAIN 1 ABS
9 3106500800 BLADE VERTICAL MN 12 ABS
10 3106300800 BAR BLADE 2 ABS
11 3100700800 BUSHING L 1 POM
12 3100700700 BUSHING R 1 POM
13 3107600300 FLAP 1 ABS
14 3108000100 MOTOR STEPPING 1 MG28GA
15 3100017510 CONTROL BOX ASS'Y 1 BUYER
15-1 3100503101 BOX CONTROL 1 P.P+G.F20%
15-2 5EPV050100 TRANS FORMER 1 DWA220A-50/60Hz
15-3 3106900300 CAPACITOR SH.M.B 1 1.0µF 400VAC
15-4 3100054400 CONTROL PCB ASS'Y 1 FR-1
15-5 3100054200 LED PCB ASS'Y 1 FR-1
15-6 3108901230 TERMINAL BLOCK 1 SN-DBW-03P
15-7 3104896300 SENSOR I.D ASS'Y 1 PTM-KD43C-D2
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
