¡ DSA-101L/DSA-121L (Before) OUTDOOR UNIT
No PART CODE PART NAME Q'TY SPEC REMARK
1 3100300501 PAN BASE 1 SECC T1.2
2 3106000900 COMP. BOLT 3 M8 x L46.5
3 3102100800 FOOT 1 SECC T1.2
4 3108134AE0 COMP. GROMMET 3 EPDM
5
3100030EE0
COMPRESSOR ASS’Y 1
RCA 100A001 101L
3100030DE0 RCA 120A001 121L
6 7400208411 WASHER PLAIN 4 M8.S x O.D22 x T1.6
7 7392800011 NUT LOCK 4 M8 x P1.25 MFZN
8 3100014100 CONDENSER ASS’Y 1
9 3100015100 BRACKET SERVICE ASS’Y 1 SECC T1.2
10 3105400700 SERVICE VALVE 1 1/2”
11 3105400800 SERVICE VALVE 1 1/4”
12 7347602011 BOLT HEX 4 M6 x L20 MFZN
13 3100020600 PIPE DISCHARGE ASS’Y 1 C1220T
14 3100020700 PIPE SUCTION ASS’Y 1 C1220T
15 3100014200 PIPE FILTER ASS’Y 1 C1220T
16 3100800600 CABINET BACK 1 ABS or AES
17 3104503800 PLATE PARTITION 1 SBHG1
18 3100601901 BRACKET MOTOR 1 SBHG1 T1.2
19 3108003010 MOTOR ODU 1 IC-9630DWLA6B
20 3101801000 FAN PROPELLER 1 ABS+G.F20% (BLACK)
21
3100029110
PANEL CONTROL ASS’Y 1
101L
3100015400 121L
21-1 3104201301 PANEL CONTROL 1 SBHG1
21-2
3109502100
CAPACITOR DUAL 1
2.0+25µF 400VAC 101L
3109502000 2.0+30µF 400VAC 121L
21-3 3101201100 CLAMP CAPACITOR 1 SBHG1
21-4 3108912300 TERMINAL BLOCK 1 SN-DBW-03P
21-5 3103800300 LOCK TWIST 1 DATL-250
21-6 3101202000 CLAMP CORD 1 NYLON
21-7 7111301511 TAPPING SCREW 1 TIS PAN 3x16 MFZN
21-8 7112403011 TAPPING SCREW 3 TIS TRS 4x30 MFZN
22 3100800701 CABINET SIDE 1 ABS or AES
23 3100800501 CABINET FRONT 1 ABS or AES
24 3104201201 PANEL ORIFICE 1 P.P
25 3101401900 COVER GRILLE 1 ABS or AES
26 3104201100 PANEL TOP 1 ABS or AES
27 3102600300 HANDLE 1 ABS or AES
28 3102100700 FOOT CUSHION 4 NBR
29 7112401211 TAPPING SCREW 19 T1S TRS 4x12 MFZN
30 7112402011 TAPPING SCREW 4 T1S TRS 4x12 MFZN
31 3106001600 SPECIAL SCREW 1 T2 4x16 MFNI LOCKING
32 7112401614 TAPPING SCREW 4 T1S TRS 4x16 MFNI+PVC/W
33 7S422X40B1 SPECIAL SCREW 4 TT2 TRS SE 4x12 MFZN
34 7112401214 TAPPING SCREW 12 T1S TRS 4x12 MFZN+PVC/W
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
