Daewoo DSA-101L User Manual

57
¡ DSA-101L/DSA-121L
No PART CODE PART NAME Q'TY SPEC REMARK
1 3100503101 CONTROL BOX 1 P.P+G.F 20%
2 3100054400 CONTROL PCB ASS'Y 1 FR-1
3 3108054200 LED PCB ASS'Y 1 FR-1
4 3103400300 KNOB RESET SWITCH 1 ABS
5 3101395060 POWER CORD ASS'Y 1 BUYER
6 3108901230 TERMINAL BLOCK 1 SN-DBW-03P
7 5EPV050100 TRANS FORMER 1 DWA220A-50/60Hz
8 3106900300 CAPACITOR SH.M.B 1 1.0µF 400VAC
H1 3102797610 HARNESS I/D COMP 1
H2 3102797500 HARNESS LED PCB 1
S 3104896300 SENSOR ID ASS'Y 1 PTM-KD-43C-D2
H3 3102794000 HARHESS POWER 1
