Oscillation (2)
19
20
X-TAL
8MHz
VDD-10%
VSS+10%
Fig 2-1
DESCRIPTION
Oscillatory Frequency drive Micom, it is made up 8MHz X-TAL oscillatory Freqency.
Ocillatory wave is as following Fig 2-1.
