¡ DSA-151L/DSA181L/DSB-181L Parts List (Indoor Unit)
No PART CODE PART NAME Q'TY SPEC REMARK
1 3100400101 BODY 1 ABS
2 3107600100 FLAP TOP 1 ABS
3 3107600200 FLAP UNDER 1 ABS
4 3106500400 BLADE VER 16 ABS
5 3103000500 HOLDER MOTOR R 1 ABS
6 3103000700 HOLDER BEARING 1 ABS
7 3103000600 HOLDER MOTOR L 1 ABS
8 3106400100 BEARING OILESS 1
9 3101800200 FAN CROSS FLOW 1 Ø100X861L
10 3102400800 GRILLE LATCH 3 POM
11
3108000230 MOTOR ASS’Y 1 IC-9425 DWKC 5C
DSB-181L
3108000230 MOTOR ASS’Y 1 IC-9425KH 6C
DSA-151L/181L
12 3102400900 GRILLE INSERT 1 ABS
13 3100501000 BOX CONTROL 1 ABS (V0)
14 3107410000 EVA ASS’Y 1
15 3101930010 FILTER ELECTRO ASS’Y 1
16 3101940010 FILTER CARBON ASS’Y 1
17 3101401300 COVER TERMINAL BLOCK 1 ABS
18 3108100100 PAN DRAIN 1 ABS
19 3102200200 FRAME GRILLE 1 ABS
20 3100000100 FILTER PRE R ASS’Y 1
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
