¡ DSA-151L/DSA-181L Parts List (Outdoor Unit)
No PART CODE PART NAME Q'TY SPEC REMARK
1 3100800101 CAB BACK 1 SECC T1.0
2 3104200500 PANEL TOP 1 SECC T1.0
3 3100800201 CAB FRONT 1 SECC T1.0
4 3101800100 FAN 1 ABS + G/F
5 3102400710 GRILLE DISCHARGE 1 PP
6 3100800301 CAB SIDE 1 SECC T1.0
7 3100300301 PAN BASE 1 SECC T1.6
8 3105300100 SUPPORTER MOTOR 1 SGCC T1.0
9 3104200601 PANEL CONTROL 1 SGCC T1.0
10 3108000520 MOTOR ODU 1 220V/60Hz
11 3106800010 CONDENSER ASS’Y 1
12 7391800011 NUT HEX 1
13 3102600100 HANDLE R 1 PP
14 3104500600 PLATE PARTITION 1 SGCC T1.0
15 310061000P BRACKET SERVICE ASS’Y 1
16 3102100200 FOOT 4 SECC T2.0
17 3102600200 HANDLE L 1 PP
18 3101200200 CLAMP WIRE 2 SGCC T1.0
19 3101200100 CLAMP CAPACITOR 1 SGCC T0.8
20 3100016300 PIPE SUCTION ASS’Y 1 CU ¡¨T0.8
DSA-151L
3100016700 PIPE SUCTION ASS’Y 1 CU ¡¨T0.8
DSA-181L
¤
¤
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
