DSA-095L PART LIST (Control PCB Assy)
No. PART CODE PART NAME SPEC. Q'TY UNIT REMARK
BD1 DS1NB80--- DIODE BRIDGE S1NB80,800V 1 EA
BZ1 3105698200 BUZZER DP-2520BA 1 EA
CA1 CN5XD104M- C-ARRAY 6P(F5)X 104Z 1 EA
CA2 CN4XD104M- C-ARRAY 5P(F4)X 104Z 1 EA
CA3 CN3XD104M- C-ARRAY 4P(F3)X 104Z 1 EA
CAP1 CMXZ2G105K CAPACITOR MYLAR 1UF,400VAC 1 EA
CC1 CCXE1H104M C-CERA 104M 50VDC 1 EA
CC10 CCXE1H103M C-CERA 103M 50VDC 1 EA
CC12 CCXE1H103M C-CERA 103M 50VDC 1 EA
CC2 CCXE1H104M C-CERA 104M 50VDC 1 EA
CC3 CCXE1H103M C-CERA 103M 50VDC 1 EA
CC4 CCXE1H103M C-CERA 103M 50VDC 1 EA
CC5 CCXE1H104M C-CERA 104M 50VDC 1 EA
CC6 CCXE1H104M C-CERA 104M 50VDC 1 EA
CC7 CCXE1H104M C-CERA 104M 50VDC 1 EA
CC8 CDXE1H104M C-MULTI CR501B-Z5U,104Z,50V 1 EA
CC9 CCXE1H103M C-CERA 103M 50VDC 1 EA
CE1 CEXE1V477C C-ELEC 470MF 35V SD 1 EA
CE2 CEXE1C107C C-ELEC 100MF 16V SD 1 EA
CE3 CEXE2W106C C-ELEC 10UF 450V SD 1 EA
CE4 CEXE2W106C C-ELEC 10UF 450V SD 1 EA
CE5 CEXE1C106A C-ELEC 10UF 16V SS 1 EA
CE6 CEXE1C475A C-ELEC 4.7UF 50V SS 1 EA
CL1 CLV-B3104M C-LINE ACROSS 275V 104K(PILKOR) 1 EA
CL2 CLV-B3104M C-LINE ACROSS 275V 104K(PILKOR) 1 EA
CLIP 3107000600 FUSE CLIP AFC-520 2 EA
CN1 3108802500 WAFER YW396-03AV 1 EA
CN2 3108802900 WAFER YW396-05AV 1 EA
CN5 3108804800 WAFER SMAW250-08 1 EA
CN6 3118700800 WAFER SMAW250-06 1 EA
CN7 3118702310 WAFER YMAW025-04R 1 EA
CY1 CH1BFB222K C CERA 2200PF,250V,Y1 1 EA
D1 DZST02D200 DIODE ST02D-200 1 EA
D2 DZUF203--- DIODE UF203 1 EA
D3 DZN4007A-- DIODE IN4007A 1 EA
FUSE 5FVLB3152L FUSE GLASS TUBE 250V/50T 3.15A 1 EA
IC1 13GS5DH9-- MICOM (MAIN) TMP87C846N-5DH9(Z) 1 EA
IC2 1TNY264P-- IC SMPS TNY264P 1 EA
IC3 1L7805CV-- IC REGULATOR L7805CV 1 EA
IC4 13GT62004A IC DRIVER ULN2004AP(M) 1 EA
IC5 1KA7042P-- IC RESET KIA7042P 5L 1 EA
IC6 13GT62004A IC DRIVER ULN2004AP(M) 1 EA
JS7 3109400100 JUMPER 10MM 1 EA
L1 52C102K000 CHOKE COIL 1MH,0.5A 1 EA
L2 52F6010100 FILTER EMI 0.6*10*3TURN 1 EA
L3 52C1374001 COIL 130UF 3A 1 EA
OSC 5PCRTL8MS0 RESONATOR CRTL8.00MSOT 1 EA
PC1 1TLP421--- IC PHOTOCOUPLER TLP421 1 EA
PC2 1TLP421--- IC PHOTOCOUPLER TLP421 1 EA
42
✔ Caution
: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
