◆OUTDOOR UNIT PART LIST; DSA-185L, 185P
No PART CODE PART NAME Q'TY SPEC REMARK
1 3110007500 PAN BASE Ass`y 1
2 3102100201 FOOT 4 SECC T2.0
3 3106000100 BOLT COMP. 3 M8xL46.5
4 3117104390 COMPRESSOR Ass`y 1 QJ250K** LG
5 3108104AE0 COMP. GROMMET 3
6 7400208411 WASHER PLAIN 3 M8.4 x 22 x T1.6
7 7392801211 NUT LOCK 3 M8xP1.25 MFZN
8 3110018920 CONDENSER Ass`y 1 L568.4xH575xW44
9 3110006110 PIPE COND. IN 1 C-1220T
10 3110006220 PIPE COND. OUT 1 C-1220T
11 3100601201 BRACKET SERVICE 1 SECC T1.6
12 3105400100 SERVICE VALVE 1 1/2" (GAS)
13 3105400210 SERVICE VALVE 1 1/4" (LIQUID)
14 7347602011 BOLT HEX 4 M6xL20 MFZN
15 311009F310 PIPE DICHARGE 1 C-1220T
16 311009F210 PIPE SUCTION 1 C-1220T
17 311009F410 PIPE CAPILLARY Ass`y 1 ID ø1.8 x L600
18 3112500300 GUIDE SUPPORT 1 SECC T1.2
19 3112400700 GRILLE COND. 1 PE
20 3110600200 BRACKET MOTOR 1 SGCC T1.2
21 3118007160 MOTOR ODU 1 YDK-50-6A
22 7348602011 BOLT HEX 4 WASHER M6xL20 MFZN
23 3101800100 FAN PROPELLER 1 ABS+G/F(10),OD420,BLK
24 3118007160 WASHER PLAIN 1 O.D.ø22 xI.D.ø8.4xT1.6
25 7392800011 NUT HEX 1 M8xP1.25 MFZN
26 3114500800 PLATE PARTITION 1 SGCC T1.0
27 3114200600 PANEL CONTROL 1 SECC T0.8
28 3108914100 TERMINAL BLOCK 1 JXO-CH-3P
29 3116905300 CAPACITOR DUAL 1 3.0+35µF
30 3101202000 CLAMP CORD 1 NYLON 66
31 3101301100 CLAMP CAPACITOR 1 SECC T1.0
32 3110800210 CABINET FRONT 1 SECC T1.0
33 3102400710 GRILLE DISCHARGE 1
34 3103510700 LABEL BRAND 1 P.C.FILM
35 3110800300 CABINET SIDE 1 SECC T1.0
36 3114200500 PANEL TOP 1 SECC T1.0
37 3102600300 HANDLE 1 ABS
38 3102101000 FOOT CUSHION 4 NBR
✔ Caution
: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
