CP-520/520A/520F Service Manual
DTV- R&D Europe
z_loc z_parts_code parts_name parts_descr remark
z_loc z_parts_code parts_name parts_descr remark
J49 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J5 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J50 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
J500 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J51 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J52 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J54 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J56 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J57 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J58 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J59 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J6 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J60 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J61 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J62 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J63 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J64 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J65 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J66 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J67 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J68 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J69 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J7 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
J70 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J71 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J72 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J73 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J74 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J76 RD-AZ202J- R CARBON FILM 1/6 2K OHM J
J78 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
J80 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J800 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J81 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J82 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J83 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
J84 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
J86 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J87 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J88 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J89 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J90 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J91 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J92 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J94 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J95 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J96 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J97 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J98 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J99 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
L101 5CPZ100K02 COIL PEAKING 10UH 3.5MM K (LAL02TB)
L350 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
L351 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
L505 5CPZ479K02 COIL PEAKING 4.7UH 3.5MM K (LAL02TB)
L506 5CPZ479K02 COIL PEAKING 4.7UH 3.5MM K (LAL02TB)
L507 5CPZ479K02 COIL PEAKING 4.7UH 3.5MM K (LAL02TB)
L508 5CPZ479K02 COIL PEAKING 4.7UH 3.5MM K (LAL02TB)
L509 5CPZ479K02 COIL PEAKING 4.7UH 3.5MM K (LAL02TB)
L510 5CPZ479K02 COIL PEAKING 4.7UH 3.5MM K (LAL02TB)
L512 5CPZ479K02 COIL PEAKING 4.7UH 3.5MM K (LAL02TB)
L513 5CPZ479K02 COIL PEAKING 4.7UH 3.5MM K (LAL02TB)
L515 5CPZ100K02 COIL PEAKING 10UH 3.5MM K (LAL02TB)
L516 5CPZ479K02 COIL PEAKING 4.7UH 3.5MM K (LAL02TB)
L523 5CPZ479K02 COIL PEAKING 4.7UH 3.5MM K (LAL02TB)
L650 5MC0000100 COIL BEAD MD-5 (HC-3550)
L801 5MC0000100 COIL BEAD MD-5 (HC-3550)
R103 RD-AZ123J- R CARBON FILM 1/6 12K OHM J
R104 RD-AZ683J- R CARBON FILM 1/6 68K OHM J
R105 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R106 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R107 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R114 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R115 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R120 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R131 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R310 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R311 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R331 RD-2Z201J- R CARBON FILM 1/2 200 OHM J
R340 RD-4Z473J- R CARBON FILM 1/4 47K OHM J
R350 RN-AZ2201F R METAL FILM 1/6 2.2K OHM F
R351 RN-AZ2201F R METAL FILM 1/6 2.2K OHM F
R370 RD-4Z159J- R CARBON FILM 1/4 1.5 OHM J
R394 RD-AZ272J- R CARBON FILM 1/6 2.7K OHM J
R395 RD-4Z394J- R CARBON FILM 1/4 390K OHM J
R396 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R401 RD-4Z272J- R CARBON FILM 1/4 2.7K OHM J
R403 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R404 RD-4Z399J- R CARBON FILM 1/4 3.9 OHM J
R405 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R407 RD-4Z182J- R CARBON FILM 1/4 1.8K OHM J
R420 RD-4Z103J- R CARBON FILM 1/4 10K OHM J
R422 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R423 RD-4Z622J- R CARBON FILM 1/4 6.2K OHM J
R500 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R501 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R502 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R503 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R504 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R505 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R506 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R507 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R508 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R510 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R511 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R514 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R515 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R516 RD-AZ153J- R CARBON FILM 1/6 15K OHM J
R517 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R518 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R519 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R527 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R528 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R529 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R530 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R531 RD-AZ181J- R CARBON FILM 1/6 180 OHM J
R532 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R533 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R534 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R537 RD-AZ183J- R CARBON FILM 1/6 18K OHM J
R538 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R539 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R540 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R541 RN-AZ3902F R METAL FILM 1/6 39K OHM F
R542 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
R543 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R544 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R545 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R546 RD-AZ181J- R CARBON FILM 1/6 180 OHM J
R547 RD-AZ563J- R CARBON FILM 1/6 56K OHM J
R551 RD-AZ823J- R CARBON FILM 1/6 82K OHM J
R552 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R553 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R554 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R555 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R556 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R557 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R558 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R559 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R560 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R561 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R562 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R563 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R564 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R565 RD-AZ154J- R CARBON FILM 1/6 150K OHM J
R566 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R567 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R568 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R569 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R571 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R572 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R573 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R574 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R575 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R576 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R577 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R578 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R579 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R580 RD-AZ123J- R CARBON FILM 1/6 12K OHM J
R581 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R582 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R583 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
