IC DESCRIPTION

I801

POWER CONTROL MODULE

PIN NO DESCRIPTION PIN NO DESCRIPTION

1 GATE DRIVE1 10 +12V INPUT

2 OCP 11 POWER CONTROL

3 SOURCE 12 +26 OUTPUT

4 GND1 13 GND2

5 GATE 14 +133V INPUT

6 GATE DRIVE2

DPM 001 TI

KSE

1234561011121314
