SWT08 5S50101090 SW TACT SKHV17910A
T401 50D0000022 TRANS DRIVE HD-15D
T402 50H0000198 FBT FSA37012M
T802 50M3541T3- TRANS SMPS TSM-3541T3
TU01 5800000032 COIL OSC DE0-006
U102 4859719130 TUNER VARACTOR DT5-NF20F
LOC PART CODE PART NAME DESCRITION
X501 5XE3R5795C CRYSTAL QUARTZ HC-49/U 3.579545MHZ 20PPM
XCS01 HXA32R768C CRYSTAL CHIP QUARTZ 32.768KHZ 20PPM 8038
XS02 5XJ16R000E CRYSTAL QUARTZ HC-49S 16.000000MHZ 30PPM
XY01 5XE3R5795B CRYSTAL QUARTZ HC-49/U 3.579545MHZ 15PPM
Z101 5PTSF5221P FILTER SAW TSF5221P
Z102 5PXPS45MB- FILTER CERA TPS-4.5MB TRAP (TAPPING)
LOC PART CODE PART NAME DESCRITION
ELECTRICAL PARTS LIST
I
I
r
OPTION PARTS LIST
1. CN-071 13" / 19" DIFFERENT PARTS LIST
LOC PART NAME
DVQ-13H1FC DVQ-19H1FC
REMARK
PART CODE DESCRIPTION PART CODE DESCRIPTION
0001 ANT ROD 4850A02510 S3BW216B (L=600 MM) X OPTION
0003 TRANS ANT MATCHING 4850A00250 IMT-06 X OPTION
C402 C MYLAR CMYH3C692J 1.6KV BUP 6900PF J CMYH3C622J 1.6KV BUP 6200PF J RETRACE
PA601 CONNECTOR 4850703S53 YH025-03+35098+ULW=500 4850703S50 YH025-03+35098+ULW=200
Q402A HEAT SINK X 4857027200 AL T1.0
Q402B SCREW TAPPTITE X 7174301011 TT2 RND 3X10 MFZN
Q402C WASHER X 4856215201 SPCC
R306 R METAL FILM RN01B471JS 1W 470 OHM J SMALL RN01B561JS 1W 560 OHM J SMALL V CENTER
R403 R METAL FILM RN01B369JS 1W 3.6 OHM J SMALL RN01B479JS 1W 4.7 OHM J SMALL HEATER
RC406 R CHIP HRFT113JCA 1/10 11K OHM J 2012 HRFT103JCA 1/10 10K OHM J 2012 X-RAY
RC502 R CHIP HRFT822JCA 1/10 8.2K OHM J 2012 HRFT682JCA 1/10 6.8K OHM J 2012 ABL
RC823 R CHIP HRFT363JCA 1/10 36K OHM J 2012 HRFT273JCA 1/10 27K OHM J 2012 OCP
V01 COIL DY 58D0000082 ODY-M1489 58D0000083 ODY-M2050
V901 CRT BARE 48A96414N1 A34JLL40X 48A96420N1 A48JLL40X(W)
ZZ131 CRT GROUND NET 48519A4710 1401S-1015-1P 48519A5110 2001S-1015-1P
ZZ132 COIL DEGAUSSING 58G0000078 DC-1400 58G0000122 DC-2030
