PARTS LIST
NO PARTS CODE PARTS NAME DESCRIPTION Q’TY REMARK
D17 3618401400 PULLEY MOTOR AS ADC-12, DS=10, DP=48.5 1 60Hz
3618401420 ADC-12, DS=10, DP=53.0 50Hz
D18 3611502000 CUSHION UPPER POM 107X31X6.7 2
D19 7650802811 BOLT HEX 6B-1 8X28 HS MFZN 2
D20 3616590220 BELT V M20.5, AGING 1
3616590230 M21, AGING
D21 3617306300 GEAR MECHANISM GM-1098-NS6X0 1 DWF-1098/68
3617306310 GM-1098-NS6P0 DWF-1098, PUMP
3617306500 GH-1398-NS6X0 DWF-1398
D22 7640802011 BOLT HEX 6B-1 8X20 SW MFZN 4
D23 3618301300 PROTECTOR GEAR SBHG 1.6T 1
D24 3615404020 VALVE DRAIN AS 5591D VE 1 NON-PUMP
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
To Next Page
