2. STRUCTURE OF THE WASHING MACHINE
3
STRUCTURE
•COLD WATER TAP
After using the washer,
close the water tap
and turn off the power.
In case of 3-wire
power cord ground
wire will not be
provided
After using the washer, course the water tap and
turn off the power
•HOOK HOLE
•HOT WATER TAP
Pour softener into the softener inlet just before
wash and will be added into the tub automatically
just before the final rinse.
•SOFTENER INLET
•TUB
•BLEACH INLET
•POWER SWITCH
•CONTROL PANEL
•ADJUSTABLE LEGS
•LINT FILTER
•PULSATOR
•COVER UNDER
•POWER CORD
•GROUND WIRE
•HOSE DRAIN
DRYTEN
INLET HOSE
COVER UNDER [OPTION]
HOSE DRAIN
WATER TAP ADAPTER
HOSE DRAIN CLAMP
Accessories
