PARTS LIST
NO PARTS CODE PARTS NAME DESCRIPTION Q’TY REMARK
A18 3611794500 DOOR F ABS 1
A19 3611504100 CUSHION DOOR CR 2
A20 3612604100 HANDLE DOOR PP 1
A21 3616008500 SPECIAL SCREW M5(T1)X10 1
A22 3610909700/10 CAP PLATE L/R ABS 1
A23 3611302900 POWER CORD AS 3X0.75, 300X2, L=1800 1 CP-2PIN
3611302800 A VCTFK 2X0.75 2.3M FLAT 2PIN
3611302600 H H05V/4A, FERRITE 1 ITALIAN 3PIN
3611303300 GTSA-3 3X0.75 ARGENTINE
A24 3618918400 UNIT FUSE FILTER AC 250V/4A, FERRITE 1
3618918400 AC 250V/8A, FERRITE
3618914810 AC 250V/5A, FERRITE TUV
A25 3612757600 HARNESS AS NON-PUMP 1
220~240:315mA(5F3GB3102L)
3612757610 SINGLE V/V
100~130:600mA(5FKGD6012S)
3612757620 PUMP
B01 3611201000 CLAMP HSW3, MFZN D36 1 NON-PUMP
B02 3613213500 HOSE DRAIN O AS EVA L=950MM 1 NON-PUMP
B03 3614514600 PLATE UPPER PP 1
B04 7112501411 SCREW TAPPING T1 TRS 5X14 MFZN 8
B05 3615302210 SUPPORTER TUB BL SPG 1.4T 1
B06 3615302310 SUPPORTER TUB BR SPG 1.4T 1
B07 3615302410 SUPPORTER TUB FR SPG 1.4T 1
B08 3615302510 SUPPORTER TUB FL SPG 1.4T 1
B09 3611413600 COVER BACK SPG 0.5T 1
B10 3618920000 ASSY CONDENSER 11.4µF+60µH 1 ~240V
3618919900 13.5µF+60µH 220V(1098)
3618921100 15.0µF+60µH 220V(1398)
3618920500 41.6µF+60µH 127V
3618920400 54.0µF+60µH 110V
B11 3612603300 HANDLE CABINET PP 1
B12 3610068700 HARNESS OUTER 50/0.18 GN ST710489-2 1
B13 4509D10020 FOOT BUTYL RUBBER 2
B14 3610310200 BASE U PP 1
3610310210 PP, PUMP
3610312200 PP(1398) DWF-1398
