38
PARTS DIAGRAM
NO. PARTS NAME PARTS CODE SPECIFICATION REMARK
A19 DOOR F 3611799210 ABS
A20 POWER CORD 3611305110 U VCTF 3*0.75 2.3M PERU
3611305500 A-VCTFK 2*0.75 2.3M GY MEXICO
3611304610 N LFC-2R 3*0.75 2.3M GY AUSTRALIA
3611336650 F H05W 3*0.75 2.3M WH CHILE
3611304810 RW-300/500 3*0.75 2.3M CHINA
3611304910 VCTF 3*0.75 2.3M INDIA
3611304710 F H05W 3*0.75 2.3M ITALY
3611305310 -H05W-F 3*0.75 2.3M WH MALAYSIA
3611305320 BS-1363A/170M/SINGAPORE SINGAPORE
3611305810 H05W-F 3*0.75 2.3M GY S/AFRICA
3611305610 F H05W 3*0.75 2.3M BK USSR, SPAIN
3611306030 H05W-F 3*0.75 2.3M GY ARGENTINA
3611302820 A-VCTFK 1.9M TAIWAN
A21 HARNESS AS 3612791000 100-127V, C&H, PUMP 200W, PUMP
3612791010 220-240V, C&H, PUMP
3612791040 100-127V, C, NON PUMP 200W, NON PUMP
3612791050 220-240V, C, NON PUMP SINGLE VALVE
3619791080 100-127V, C&H, NON PUMP 200W, NON PUMP
3612791090 220-240V, C&H, NON PUMP DUAL VALVE
3612791200 100-127V, C, NON PUMP 260W, NON PUMP
3612791210 220-240V, C, NON PUMP SINGLE VALVE
3612791240 100-127V, C&H, NON PUMP 260W, NON PUMP
3612791250 220-240V, C&H, NON PUMP DUAL VALVE
A22 UNIT BUBBLE AS 3618946410 100-130V, CDK-115K 260W
3618946320 220-240V, CDK-230K
A23 HINGE DOOR 3612902400 POLYACETAL
A24 UNIT FILTER AS 3614161420 DWLF-K11-2 OPTION
A25 UNIT COIL AS 3618909130 60±10µH, #1806, 3P 110V/60HZ, 260W
B01 HOSE DRAIN O 3613213560 1089 CTE 950MM NON PUMP
HOSE DRAIN O AS 3613218800 LD-PE/EVA L=1600 PUMP PUMP
B02 PLATE UPPER 3614514600 PP
B03 SCREW TAPPING 7112501411 T1 TRS 5*14 MFZN
B04 SUPPORTER TUB BL 3615302210 SPG 1.4T
B05 SUPPORTER TUB BR 3615302310 SPG 1.4T
B06 SUPPORTER TUB FL 3615302410 SPG 1.4T
B07 SUPPORTER TUB FR 3615302510 SPG 1.4T
B08 COVER BACK 3611413600 SPG 0.4T
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
