PARTS DIAGRAM
A01 36142T4000 PANEL A ABS, DWF-262AX 1
A02 3615511900 WINDOW COURSE ABS-TR, DWF-262AX 1
A03 3615512000 WINDOW FUNCTION ABS-TR, DWF-262AX 1
A04 3616647900 BUTTON FUNCTION ABS, DWF-262AX 1
A05 3613409100 KNOB DAIL ABS, DWF-262AX 1
A06 3616648000 BUTTON OPTION ABS, DWF-262AX 1
A07 3616647800 BUTTON PS ABS, DWF-262AX 1
A08 3615511800 WINDOW DISPLAY ABS-TR, DWF-262AX 1
A09 PRPSSW4N30 PCB AS MEXICO, DWF-262AX 1
A10 36142T4000 PANEL B ABS, DWF-262AX 1
A11 3614542400 PLATE T ABS, 260AX 1
A12 3612902400 HINGE DOOR POM 2
A13 36111T2L00 CASE DETERGENT ABS 1
A14 3610907800 CAP SOFTENER PP 1
A15 7112503011 SCREW TAPPING T1S,TRS,5X30 MFZN 2
A16 3611561400 CUSHION DOOR NBR,DWF-200A 2
A17 36117ADJ00 DOOR ABS, DWF-262AX 1
A18 3611559900 CUSHION DOOR NR 2
A19 3615118400 SPRING DOOR R PW(SWP)D=2.0 1
A20 3615118300 SPRING DOOR L PW(SWP)D=2.0 1
A21 3619045400 MICRO SWITCH GSM-V16183A4, 250V/16A 1
A22 36190470B0 SAFETY SWITCH SF-030A31 1
A23 3614801630 SENSOR PRESSURE AS CDN15N,180_,3PIN 1
A24 3618912200 UNIT CAPACITOR AS 45.6UF,200VAC,CAN TYPE 1
A25 3610394400 NOZZLE DETERGENT PP 1
A26 3618110900 BODY DETERGENT ABS 1
A27 3615416310 VALVE INLET DR-12AS:C-R-H.110-130V50/60HZ 1
A28 3618946412 UNIT BUBBLE PUMP AS C DK-115K1, H:350MM 1 127V/60Hz
A29 36160077400 SPECIAL SCREW T2S TRS 4X10+24 2
A30 361279C230 HARNESS AS DWF-262AX 110V PUMP NB C-H-R 1
A31 3611338300 CORD POWER AS 750M,201AS, EP3PIN 1
■
Parts List
No. PARTS CODE PARTS NAME DESCRIPTION Q'TY REMARK
To Next Page
