PARTS DIAGRAM
NO PART CODE PARTS NAME EA DESCRIPTION REMARK
A26 3611521700 CUSHION DOOR 4 CR
A27 3611405101 COVER L 1 ABS LEFT
A28 7121401608 SCREW 8 T2S PAN 4x16 SUS
3612725100 NON-PUMP
A29 3612725110 HARNESS ASS¡flY 1 PUMP
3612725120 NON-PUMP, SINGLE VALVE
3615403510 AC 110-130V/60Hz
A30 3615403710 VALVE INLET COLD 1 AC 220-240V/50Hz
3615402010 AC 220V/60Hz
3615403630 AC 110-130V/60Hz
0EA;SINGLE VALVE
A31 3615403830 VALVE INLET HOT 1 AC 220-240V/50Hz
0EA;SINGLE VALVE
3615402130 AC 220V/60Hz
0EA;SINGLE VALVE
A32 7121301208 SCREW 2 T2S TRS 3x12 SUS
B01 3612200100 FRAME T 1 PP
B02 3610805600 CABINET AS 1 PAINTING
B03
3610303130
BASE U 1
PP NON-PUMP
3610303110 PP PUMP
B04 - - - -
B05 3617702000 LEG ADJUST 2 PP
B06 3612100300 FOOT 2 PP
B07 4509D10020 FOOT 2 RUBBER BUTYL
B08 - - - -
3610076130 54.0¥F+60¥H, L=470 110V
B09
3610076230
ASSY CONDENSER 1
41.6¥F+60¥H, L=470 127V
3610032630 13.5¥F+60¥H, L=470 220V
3610031930 12.5¥F+60¥H, L=470 240V
B10 3612600700 HANDLE CABINET 2 PE-HD
B11 3610068700 ASSY EARTH 1 50/0.18 GREEN ST710480-2
B12 - - - -
B13 3611402800 COVER BACK 1 PP
B14 3614504300 PLATE UPPER 1 PP
B15
3613214200 HOSE DRAIN O AS 1 L=1000 NON-PUMP
3613203101 HOSE AS 1 DWF-5230PN PUMP
B16 3612502300 GUIDE DRAIN HOSE 1 PP PUMP
B17 3611201000 CLAMP 1 HSW3,D2.6,MFZN,D36 NON-PUMP
