PARTS DIAGRAM
NO PART CODE PARTS NAME EA DESCRIPTION REMARK
B15
4509M56000 HOSE DRAIN 1 L=930mm NON-PUMP
3613203101 HOSE AS 1 DWF-5230PN PUMP
B16 3612502300 GUIDE DRAIN HOSE 1 PP PUMP
B17
4501F06120 CLAMP 1 SWPA2 ZN8-C NON-PUMP
3611200200 CLAMP B 1 SW D2.6 ZN8-C PUMP
B18
3618703700 TERMINAL PUMP 1 250V/1A PUMP
618703720 125V/3.15A PUMP
B19 3611405320 COVER PUMP 1 PP PUMP
B20 7122501611 SCREW TAPPING 3 T2 TRS 5x16 MFZN PUMP
3963220330 AC 110V/60Hz PUMP
B21
3963821530
MOTOR SHADED POLE 1
AC 120V/60Hz PUMP
3963322730 AC 220V/60Hz PUMP
3963513430 AC 220-240V/50Hz PUMP
B22 3611901530 FILTER AS 1 DWF-5590DPNF, E-TYPE PUMP
3618912600 AC 250V/4A, FERRITE
B23 3618912630 UNIT FUSE FILTER 1 AC 250V/5A, FERRITE TUV
3618912610 AC 250V/8A, FERRITE
3611301300 3x0.75, 300x2, 300-RTML ITALIAN 3PIN
4508B81001 3x0.75, 300x2, 300-RTML CP-2PIN
B24 450E181000 POWER CORD AS 1 3x0.75, 300x2, 300-RTML 3-WIRE
WAK42H762- A VCTFK 2x0.75, 2.3M FLAT 2PIN
450KA81003 3x0.75, 300x2, 300-RTML EUROPE-2PIN
C01 3618101400 NOZZLE BODY 1 PP
C02 4509M83030 COVER TUB O 1 PP
C03 3610065800 SUSPENSION AS(A) 2 DWF-9290RD
C04 3610065900 SUSPENSION AS(B) 2 DWF-9290RD
C05 4509M83012 TUB O 1 PP
C06
4509M06010
HOSE OVERFLOW 1
PE-LD NON-PUMP
3613205400 FRPP PUMP
C07
4509K78000 VALVE DRAIN AS 1 NON-VE NON-PUMP
3617100510 ELBOW DRAIN 1 PP PUMP
450ED45030 AC 110-130V/60Hz NON-PUMP
C08
3966320220
MOTOR SYNCHRONOUS 1
AC 220V/60Hz NON-PUMP
3966010130 AC 220-240V/50Hz NON-PUMP
450ED45040 AC 110-130V/60Hz PUMP
To Next Page
