Components disassembly pictures
1 1
3. LOUVER F-A
1. ERF-310A, 340A, 370A, 310M,
340M, 370M
1) Remove 2 fixing screws
2) Remove Louver F A with hand
2) Remove flap link fixing screw
Take out flap link
3) Remove Hall Pcb As by pressing the fixture
ribs with the fingers
To Next Page
