Components disassembly pictures
2) Take out Panel Control by pulling it up and forward
and detach Switch Lamp harness by pressing
the housing with fingers
12. Door Switch
1. ERF-310A, 340A, 370A, 310M,
340M, 370M
1) Remove the door switch sliding by its guide
13. Gasket
1. ERF-310A, 340A, 370A, 310M,
340M, 370M
1) Take off the gasket as shown
2) Fix the new one
