Components disassembly pictures
13) Detach D-Timer housings from Relay harness
14) Detach Relay harness from Condenser
19. Compressor
1. ERF-310A, 340A, 370A, 310M,
340M, 370M
1) Remove 2 welded points
2) Take out the four compressor fixture with a
flat screwdriver
