Daewoo ERF-364MBB User Manual

EXPLODE
DRAWING
Nº
PART
CODE
PART NAME COLOR
HANDLE
TYPE
SPARE
PRICE
ERF-364MBB
(ERF-366MN)
ERF-364MBB
(ERF-366MNL)
ERF-364MBW
(ERF-366MNL)
ERF-364MBI
(ERF-366MN)
ERF-364MBI
(ERF-366MNL)
ERF-364MBT
(ERF-366MN)
ERF-364MBT
(ERF-366MNL)
ERF-384MBB
(ERF-386MN)
ERF-384MBB
(ERF-386MNL)
ERF-384MBW
(ERF-386MN)
ERF-384MBI
(ERF-386MN)
ERF-384MBI
(ERF-386MNL)
ERF-384MBT
(ERF-386MNL)
REMARKS
1 3017839400 GLASS SHELF (INSERT TYPE) '04 4,54 3 3 3 3 3 3 3 3 3 3 3 3 3
4 3001402200 COVER GLASS V/CASE (INSERT TYPE) ERF**4 3,10 1 1 1 1 1 1 1 1 1 1 1 1 1
5
DMS1181980 CASE VEGETABLE *L '04 TRANSPARENT DAEWOO 2006
4,70 1 1 1 1 1 1 1 1 1 1 1 1 1
6
DMS1182080 CASE VEGETABLE *R '04 TRANSPARENT DAEWOO 2006
4,70 1 1 1 1 1 1 1 1 1 1 1 1 1
7 3011163200 CASE ICING 0,51 1 1 1 1 1 1 1 1 1 1 1 1 1
8
DMS1115950
CASE FD (WITHOUT PRINTING) 3,71 1 1 1 1 1 1 1 1 1 1 1 1 1
9
DMS1115310
CASE FB (WITHOUT PRINTING) 6,14 2 2 2 2 2 2 2
9 DMS1115410 CASE FC (WITHOUT PRINTING) 6,62 2 2 2 2 2 2
10 DMS1115250 CASE FA WITHOUT PRINTING 7,36 1 1 1 1 1 1 1 1 1 1 1 1 1
11 3013337100 INSULATOR MULTI DUCT M 36../ 38.. / 40 1,08 1 1 1 1 1 1 1 1 1 1 1 1 1
12 3012756600 HARNESS THERMO-TIMER A 1,28 1 1 1 1 1 1 1 1 1 1 1 1 1
13 3012756610 HARNESS THERMO-TIMER B 0,95 1 1 1 1 1 1 1 1 1 1 1 1 1
14 3018120910 THERMOSTAT GNF-176DB (OFF POSITION) 3,50 1 1 1 1 1 1 1 1 1 1 1 1 1
15 DMS1452040 COVER MULTI DUCT 36../ 38.. / 40.. (OFF POSITION) 3,13 1 1 1 1 1 1 1 1 1 1 1 1 1
16 3017903900 SOCKET R LAMP AS 0,56 1 1 1 1 1 1 1 1 1 1 1 1 1
17 3013600700 LAMP 0,44 1 1 1 1 1 1 1 1 1 1 1 1 1
18 3015503300 WINDOW LAMP 0,34 1 1 1 1 1 1 1 1 1 1 1 1 1
19 3013401410 KNOB R 0,11 1 1 1 1 1 1 1 1 1 1 1 1 1
20 3018128310 SWITCH D TIMER (INVENSYS) CF-3001-21 3,32 1 1 1 1 1 1 1 1 1 1 1 1 1
21 3017045600 EVAPORATOR AS 10,85 1 1 1 1 1 1 1 1 1 1 1 1 1
22 3012702400 SWITCH BI-METAL-FUSE 1,46 1 1 1 1 1 1 1 1 1 1 1 1 1
23 3012806752 HEATER D AS MECH 4,27 1 1 1 1 1 1 1 1 1 1 1 1 1
24 3010615600 BRACKET FAN MOTOR 0,33 1 1 1 1 1 1 1 1 1 1 1 1 1
25 3011804710 MOTOR FAN AS SHAFT 3,17 A GRADE 230V/50HZ 5,33 1 1 1 1 1 1 1 1 1 1 1 1 1
26 DMS8905501 LOUVER FB 36./39. 3,45 1 1 1 1 1 1 1
26 3018905601 LOUVER FB 38./41. 3,78 1 1 1 1 1 1
27 3011801410 FAN GRADO A 0,33 1 1 1 1 1 1 1 1 1 1 1 1 1
28 3011200520 FIXTURE FAN RING (SPRING) DAEWOO 2005 0,05 1 1 1 1 1 1 1 1 1 1 1 1 1
29 3018913800 LOUVER FA 36./39. 3,32 1 1 1 1 1 1 1
29 3018913900 LOUVER FA 38./41. 3,76 1 1 1 1 1 1
30 3010107100 ABSORBER FAN MOTOR 0,05 2 2 2 2 2 2 2 2 2 2 2 2 2
31 - ASSY CAB URT 36,, - 1 1 1 1 1 1 1
31 - ASSY CAB URT 38,, - 1 1 1 1 1 1
32
DMS1494310 COVER *T HINGE SNOW WHITE
WHITE 0,31 1 1
32
DMS1494340 COVER *T HINGE (N/G)
NOBLE GREY 0,31 1 1 1 1 1 1 1
32
DMS1494330 COVER *T HINGE (BLACK)
BLACK 0,28 1 1 1 1
33
3012922600 HINGE *T AS
1,20 1 1 1 1 1 1 1 1 1 1 1 1 1
34 3016004900 SPECIAL BOLT C 0,10 9 9 9 9 9 9 9 9 9 9 9 9 9
35
DMS1477510 COVER CAB HARNESS SNOW WHITE
WHITE 0,09 1 1
35 DMS1477540 COVER CAB HARNESS (NOBLE GREY) NOBLE GREY 0,09 1 1 1 1 1 1 1
35
DMS1477530 COVER CAB HARNESS (BLACK)
BLACK 0,09 1 1 1 1
36
3011755200 SWITCH DOOR SNOW WHITE
WHITE 0,50 1 1
36
3011783400 SWITCH DOOR NOBLE GREY
NOBLE GREY 0,54 1 1 1 1 1 1 1
36 3011782900 SWITCH DOOR (BLACK) BLACK 0,54 1 1 1 1
37 DMS0920210 CAP SCREW ( (DARK GREY) DARK GREY 0,02 OUT OF USE
BUYER Nº
DATE
REV
A134
24/06/2009
0
DESA
DESADESA
DESA PRICE PARTS LIST ERF**4M BAR HANDLE MODELS
PRICE PARTS LIST ERF**4M BAR HANDLE MODELSPRICE PARTS LIST ERF**4M BAR HANDLE MODELS
PRICE PARTS LIST ERF**4M BAR HANDLE MODELS
