12
PART DETAILS
Freezer Duct (FD,SD-650F Type)
Freezer Evaporator, Fan (FD,SD-650F Type)
Lamp & Fan Motor Connectors
Evaporator Fan
Motor Blade
Evaporator
Thermal
Fuse
Evaporator
Evaporator Coil Heater
F-Sensor
Heater Connectors &
Sensor Connectors
Evaporator Fan
Motor Guard
Duct (A)
Duct (B)
FD,SD-650R,1250R¿ 12– ` (¿) 02.8.21 4:48 PM ˘`12
