42
REPLACEMENT OF MAIN COMPONENTS
G. Replacing evaporator fan motor
F-1. Pull out the fan motor’s connector.
F-2. Unscrew the four screws which located on bottom of fan motor.
H. Replacing F/D-Sensor or R/D-Sensor
H-1. F-Sensor of Freezer
Unscrew as illustrated below and pull-out the F-Sensor from the cover.
F-Sensor
(Orange Color)
