MAIN COMPONENTS
1.COMPRESSOR
Refrigerant R12
Voltage
100V/50,60 110V/60
115,120V/60 127V/60 220V/50 220V/60 230V/50 240V/50
Comp model
DS22LCF1 DS22LCF1 DS22LCF1 DS22LCF1 DS22LCS8 DS22LCS8 DS22LCS8 DS22LCS8
Part Code
3951122X10 3951122X10 3951122X10 3951122X10 3954122X80 3954122X80 3954122X80 3954122X80
Start type
RSIR RSIR RSIR RSIR RSIR RSIR RSIR RSIR
Refrigerant R134a
Voltage
100V/50,60 110V/60
115,120V/60 127V/60 220V/50 220V/60 230V/50 240V/50
Comp model
DS25LHF0 DS22LHF1 DS22LHF1 DS25LHF2 DS22LCS8 DS22LCS8 DS22LCS8 DS22LCS8
Part Code
3951125Y00 3951125Y10 3951125Y10 3954107F50 3954107F50 3954107F50 3954107F50
Start type
RSIR RSIR RSIR RSIR RSIR RSIR RSIR RSIR
2. RELAY ASSEMBLY
Refrigerant R12
Voltage
100V/50,60 110V/60
115,120V/60 127V/60 220V/50 220V/60 230V/50 240V/50
Relay model
197SHB,S068 197SHB,S068 197SHB,S068 197SHB,S068 129RFB,S220 129RFB,S220 129RFB,S220 129RFB,S220
Part Code
3018101411 3018101411 3018101411 3018101411 3018123030 3018123030 3018123030 3018123030
Refrigerant R134a
Voltage
100V/50,60 110V/60
115,120V/60 127V/60 220V/50 220V/60 230V/50 240V/50
Relay model
734RFB,S068 174SHB,S068 174SHB,S068 213THB,S068 129SHB,S220 129SHB,S220 129SHB,S220 129SHB,S220
Part Code
3018122250 3018108140 3018116175 3018123121 3018123080 3018123151 3018116310 3018122201
3.CONTROL SWITCH
Refrigerant R12
Voltage
100V/50,60 110V/60
115,120V/60 127V/60 220V/50 220V/60 230V/50 240V/50
Relay model
PFN -110U-02D PFN -110U-02D PFN -110U-02D PFN-110U-02D PFN -110U-02D PFN-110U-02D PFN -110U-02D PFN-110U-02D
Part Code
3018303100 3018303100 3018303100 3018303100 3018303100 3018303100 3018303100 3018303100
Refrigerant R134a
Voltage
100V/50,60 110V/60
115,120V/60
127V/60 220V/50 220V/60 230V/50 240V/50
Relay model
PFN -110U- 02SS PFN -110U- 02SS PFN -110U- 02SS PFN -110U- 02SS PFN -110U-02D PFN -110U-02D PFN-110U- 02SS PFN-110U-02SS
Part Code
3018303110 3018303110 3018303110 3018303110 3018303100 3018303100 3018303110 3018303110
4. DRYER
Refrigerant R12 R134a
Spec. 10g 10g
Part code 3016801301 3016801301
Hz Hz
Hz Hz Hz Hz Hz HzHzHz
Hz
Hz Hz Hz
Hz Hz Hz Hz Hz HzHzHz
Hz Hz Hz Hz Hz Hz Hz Hz
Hz Hz Hz Hz Hz
Hz Hz Hz Hz Hz Hz Hz
Hz Hz Hz Hz Hz Hz
