1 2
■
Ice tray
Fill tray 3/4 full to allow expansion of water during freezing. Place tray in freezer
chest. To release cubes, twist lid slightly.
■
Removable shelf
Shelves can be removed by pulling forward. The shelf can be placed at your
desirable position.
■
Freezer Shelf
To remove the freezer shelf!
1. Remove the screw on the left of inside freezer shelf with screw driver.
2. Push the shelf hooks to the back slightly and remove it by lifting off the slots of
bottom side.
3. Reverse procedure to install.
■
Defrost Drain Vessel
To remove defrost drain vessel.
1. Lift the defrost drain vessel slightly, then rotate bottom out and pull it down.
2. Reverse procedure to install.
Take a moment to know all the features and convenience it was designed to provide.
Numbers match those in the illustration on page 1.
Here are the features of your new refrigerator.
!
@
&
)
*
(
%
#
$
^
2
1
3
4
5
6
!
FREEZER DOOR GASKET
@
FREEZER POCKET
#
FREEZER REMOVABLE SHELF
$
FREEZER TEMPERATURE
CONTROL KNOB
%
ICE TRAY
^
ICE BOX
&
REFRIGING-ROOM DOOR GASKET
*
EGG POCKET
(
REFRIGING-ROOM POCKET
(
SMALL
)
)
REFRIGING-ROOM POCKET
(
LARGE
)
1
LAMP COVER
2
REFRIGERATOR TEMPERATURE
CONTROL KNOB
3
REMOVABLE SHELF (LARGE)
4
GLASS SHELF
5
VEGETABLE BOX
6
CHILLED TRAY
FEATURE CHART
