Methods of exchanging main parts
6. Defrost heater
1) Unscrew the one screws securing the evapoator.
2) Pull the accumulator slightly to the arrow direction.
3) Move evaporator forward as the figure and make working
space to remove glass heater whith situates under the bottom
of evaporator.
(This is the same removing procedure as. However, do not
remove the welded points.)
*Take care not to brnd the pipe connrcted to accumulator.
4) Take out the defrost heater from the heater fixure without
removing the heater cover (upper,lower) (Donot apply too
much force on the heater fixture.)
Evaporator fastening screw
Heater cover (Lower)
Heater cover (Upper)
Defrost heater
Heater fixture
6
